Main Parameter：

1、 Overall size:45.5m x10.6m ×4.5m (for reference only)
2、 Machine size:39.6m ×2.5m ×3.2m(based on the product provided by client)
3、 Design speed：400pcs per minute
4、 Work speed:250-350pcs per minute
5、 Rejection rate:≥2%(excluding scrap caused by hot melt, materials splicing or joint)
6、 Power source：380V,50HZ/60HZ(3 phase,4 lines +ground wire)
7、 Machine capacity：400KW approximately
8、 Air pressure:0.6-0.8Mpa
9、 Machine weight：97Tons approximately

Configuration：

1、Product structure:Upper&lower tissue（or airlaid），Cotton core（mix with SAP）.Topsheet hydrophilic nonwoven，ADL，Leak cuff hydrophobic nonwoven，Back sheet，Waistline nonwoven，Waist nonwoven，Waist elastic，Pouch filmffor Menstrual Pant）.
2、Product size:Adult Pant 700mm*780mm，Menstrual Pant 560mm*620mm，to be customized.
3、Program system:Servo driven，intelligent HMI touch screen man-machine interface.
4、Tension system:Tension control with buffer system，automatic web guiding system，to ensure materials stable working at ZERO speed splice.
5、Driven system:Servo drive，digital size change，ensure run synchronously at full process.
6、Safety system:Safety guard for operating side，emergency stop switch，security identifier，safety pull wire at driven side.
7、Packaging system:Auto stacker（dual push dual exit）and auto bagger to be defined by customer need
8、Web guiding system:Germany BST/USA FIFE.Customized function available
