ADUM1201ARZ ADI Digital Isolators
Parameter
| Manufacturer |
Analog Devices Inc. |
| Product Category |
Digital Isolators |
| Mounting Style |
SMD/SMT |
| Package / Case |
SOIC-8 |
Series
|
ADUM1201
|
Supply Voltage - Min
|
2.7V
|
Supply Voltage - Max
|
5.5V |
Minimum Operating Temperature
|
- 40 C
|
Maximum Operating Temperature
|
+ 105 C
|
Packaging
|
Tube
|
Factory Pack Quantity
|
98 |
Introduction
ADUM1201ARZ is a digital isolator manufactured by Analog Devices. Digital isolators are used to provide galvanic isolation between two circuits, allowing data transmission while preventing electrical noise and ground loops.
This device has two channels, each with a data rate of up to 25 Mbps. It provides isolation up to 2.5 kV RMS for 1 minute and has a wide operating temperature range of -40°C to +105°C. It also has a small footprint and low power consumption.
The "ARZ" in the part number indicates that this device is in a 16-pin SOIC package. The "ADUM1201" indicates the device's family and size.
Overall, ADUM1201ARZ is a reliable and high-performance digital isolator suitable for a wide range of applications, including industrial automation, medical equipment, and communication systems.
Application
ADUM1201ARZ is a digital isolator that can be used in various industry applications that require galvanic isolation between two circuits. Here are some common use cases:
1.Industrial Automation: can be used in industrial automation applications such as process control systems, factory automation, and robotics.
2.Medical Equipment: can be used in medical equipment such as patient monitoring systems, diagnostic equipment, and medical imaging systems.
3.Communication Systems: can be used in communication systems such as Ethernet, USB, CAN, and SPI interfaces to provide galvanic isolation and prevent electrical noise and ground loops.
4.Automotive Electronics: can be used in automotive applications such as in-vehicle infotainment, engine management systems, and body control systems.
5.Energy Management: can be used in energy management systems such as smart meters, solar controllers, and wind controllers.
6.Aerospace Systems: can be used in aerospace systems such as avionics, flight control systems, and radar systems.
Overall, ADUM1201ARZ is a reliable and high-performance digital isolator suitable for a wide range of industry applications that require galvanic isolation between two circuits. Its small footprint and low power consumption make it suitable for portable and battery-powered devices as well.
Packaging
All integrated circuits are in original factory packaging.
