Parameters

Performance index

CCD Type

1/3″SONY CCD

Pixels

PAL:512(H)＊582(V) NTSC:512(H)＊492(V)

TV SYSTEM

PAL/NTSC

Horizontal Resolution

420 / 480 / 540 / 600 / 700TVL

illumination

0Lux/F1.2

Lens

3.6mm for standard （2.8 / 3.6/ 6/ 8/ 12/ 16 ）

Backlight compensation

Auto

Electronic shutter

1/50 (1/60) -1/100,000Sec

White Balance

Auto

Sync

Inter-sync

SNR

≥48dB

Gamma correction video

＞0.45

TV-OUT

1.0Vp-p75Ω

LED length

850nm

LED number

18pcs

IR distance

5-15m

Power

DC12V

operating current

﹤260mA

Working Tem

-20℃-+85℃

size

73（L）*88(H)*60(D)mm
