Air Conditioner Compressor Systems Frequency Transforming Cabinets

Air Conditioner Compressor Systems Frequency Transforming Control Panel Cabinets.

typical applications: constant pressure water supply, air compressor, air compressor, air pump, central air conditioning, port machinery, machine tools, boilers, paper machinery, food machinery, etc.



Air Conditioner Compressor Systems Frequency Transforming Cabinets

1. Material: Cold Rolled Steel Sheet or Stainless Steel SUS304

2. Surface Treatment: Etch Primer for Box Body and Door Plate, Powder Coating for Outside, Texture Optional as RAL7032 or RAL7035,Mounting Plate is galvanized.

3. Class of Protection: IP56(According to GB4205-1993)   PU Foaming Sealing



Item Name:

Industrial air compressor control cabinet ,Air Conditioner Compressor Systems Frequency Transforming Cabinets

Material:

Cold Rolled Steel Sheet or Stainless Steel

Thickness:

Cabinet Body 2.0mm Door Plate:2.5mm Mounting Plate:2.5mm

Standard Configuration:

Door Plate, Cabinet Body, Sealing Strip, Grouping Sets, Mounting Plate, Door Lock

Surface Treatment:

Etch Primer for Cabinet Body and Door Plate, Powder Coating for Outside, Texture Optional as RAL7032 or RAL7035,Mounting Plate is galvanized.

Class of Protection:

IP56(According to GB4205-1993)

MOQ:

100 PCS

Supply Ability:

10000 PCS/Month

Delivery Time:

10-15 days

Remark:

Special Demands Can Be Customized



Main advantage of Industrial air compressor control cabinet :

1.   The door plate and box body are installed with special screws and retainers in accordance with common standards, which can ensure the protection class and the operation and maintenance in the narrow space in the box.

2.   Multiple protection grooves are designed at the box opening can not only reinforce the structure but also prevent the entry of dirt or water when the door is opening.

3.   PU foaming sealing strip ensures a protection class of IP56 to box body.

4.   The grounding line can be connected to the box body and door plate.

5.   Racks with screw holes are provided on both sides of the box to ensure the max mounting height and ensure the installation of supporting rail or mounting plate.

6.   The special plastic insulating sleeve can provide sealing and prevent door plate screw loosening, and guide screws when they are tightened.





Air Conditioner Compressor Systems Frequency Transforming Cabinets



Air Conditioner Compressor Systems Frequency Transforming Cabinets





Air Conditioner Compressor Systems Frequency Transforming Cabinets
