Overview
Brand Name: Alactel
Product Number: 3HE11240AA
Disription: Alcatel 3HE11240AA is QSFP (Quad Small Form-factor Pluggable) Transceiver, operating over Double Fiber Single-Mode Fiber (SMF) optical cable.
Specification
|
Media Type:
|
Double Fiber Single-Mode Fiber (SMF.)
|
|
Maximum Distance:
|
40km
|
|
Transceiver Type:
|
QSFP
|
|
TX Wavelength:
|
1310 nm.
|
|
RX Wavelenght:
|
1310 nm.
|
|
Minimum Optical Budget:
|
16.3 dB
|
|
Supported Data Rate:
|
39.81–44.8 Gbps
|
|
Supported Applications:
|
40G Ethernet (41.25Gbps), STM-256 (39.81 Gbps), OTU3 (43.01Gbps), OTU3e2 (44.58Gbps)
|
|
DDM/DOM:
|
Supported
|
|
Temperature Range:
|
Standard 0°-70°C
|
|
Connectors:
|
Double LC
|
|
Tx Wavelength Bandwidth:
|
4 WDM Seperated 1310nm Lanes (13nm (1271, 1291, 1311, 1331))
|
|
Rx Wavelength Bandwidth:
|
4 WDM Seperated 1310nm Lanes (13nm (1271, 1291, 1311, 1331))
|
|
Minimum Transmitting Power:
|
Each Lane -2.7 dB
|
|
Maximum Transmitting Power:
|
Each Lane 4.5 dB
|
|
Receiver Sensitivity:
|
Each Lane -19 dB
|
|
Receiver Overload:
|
Each Lane -7 dB
|
|
Transmitter Type:
|
DFB Laser
|
|
Receiver Type:
|
APD Photodiode
|
|
Power:
|
+3.3V single power supply
|
|
Chipset:
|
MAXIM, MINDSPEED, SEMTECH, UX
|
|
Compliance:
|
802.3ba 40GBASE-ER4, CE, Class 1 FDA and IEC60825-1 Laser Safety Compliant, INF-8438i, QSFP+ MSA, RoHS, SFF-8436
|
