Allen-Bradley 1756-IF16
The ControlLogix® Architecture provides a wide range of input and output modules to span many applications, from high-speed digital to process control. The ControlLogix architecture uses Producer/Consumer technology, which allows input information and output status to be shared among multiple ControlLogix controllers.
Technical Specifications
| Attribute |
1756-IF16/A |
| Inputs |
16 single ended, 8 differential or 4 differential (high speed) |
| Input range |
±10V
0...10V
0...5V
0...20 mA |
| Resolution |
320 μV/count (15 bits + sign bipolar) @ ±10.25V
160 μV/count (16 bits) @ 0...10.25V
80 μV/count (16 bits) @ 0...5.125V
0.32 μA/count (16 bits) @ 0...20.5 mA |
| Current draw @ 5.1V |
150 mA |
| Current draw @ 24V |
65 mA |
| Power consumption |
2.33 W |
| Power dissipation |
Voltage: 2.33 W
Current: 4.00 W |
| Thermal dissipation |
Voltage: 7.93 BTU/hr
Current: 13.65 BTU/hr |
| Input impedance |
Voltage: ≥10 MΩ
Current: 249 Ω |
| Overvoltage protection, max |
Voltage: 30V DC
Current: 8V DC |
| Normal mode noise rejection |
>80 dB @ 50/60 Hz |
| Common mode noise rejection |
>100 dB @ 50/60 Hz
|
