Brand Name                 AB

Product reference      1769-L30

The Allen-Bradley 1769-L30 compact Logix processor module can support up to 16 I/O modules with 2 expansion cables on a maximum of 3 I/O banks. Each I/O bank requires its own power supply, and only one 1769-L30 processor module or any Logix controller module can be connected to a compact Logix system at a time. The 1769-L30can be used anywhere in an industrial area. The 1769-L30 can communicate with any device through an RS-232 port with either a 1747-CP3 or a 1756-CP3 programming cable. It has a user memory of 256 KB and runs an RX5000 software.

The 1769-L30 has a current backplane of 800 mA at +5V DC and 0 mA at +24V DC. It has an operational temperature range between 0° to 60°C (32° to 140°F), at a 5% to 95% non-condensing relative humidity. The 1769-L30 has a key switch on the front panel for controlling the operation mode. The 1769-L30 has the following key switch functions (RUN, PROG, REM) which can either be used to run the program, enable or disable outputs, or change between the remote program on the controller. The 1769-L30 can be mounted using either a panel mounting or a DIN rail. It has an operational vibration of 10G at 500HZ and a shock rating of 30G.

The 1769-L30 has a weight of 360g (0.792 lbs), and a dimension of 118 mm (4.649 in.) by 50 mm (1.97 in.) by 87 mm (3.43 in.). It has a 1747-BA battery, a 1 kV galvanic gun surge immunity (IEC61000-4-5), and a 10V, 0.15 to 80 MHz IEC61000-4-6 certified conduction immunity.

Analog I/O Modules Choose analog, thermocouple, or RTD modules for these features:

 • Individually configurable channels

 • Ability to enable and disable channels individually

 • Onboard scaling • Auto calibration of inputs

• Online configuration

 • Selectable input filters

• Over-range and under-range detection and indication

• Selectable response to a broken input sensor

• Selectable power source

• Input modules offer both single-ended or differential inputs

 • Ability to direct output device operation during an abnormal condition

• High accuracy ratings The data can be configured on board each module as:

 • Engineering Units in volts or milliamps.

 • Scaled-for-PID.

 • Percent of range.

 • Raw/Proportional Data for maximum resolution.
