Allen Bradley 2713P-T12WD1 PanelView

Allen-Bradley 2713P-T12WD1 PanelView



Allen Bradley 2713P-T12WD1 PanelView Original And Brand New In Stock



Overview For 2713P-T12WD1

The PanelView™ 5310 terminals are operator interface devices that monitor and control devices attached to
ControlLogix® 5570 and 5580 controllers, and CompactLogix™ 5370, 5380, and 5480 controllers over an EtherNet/IP™
network. Animated graphic and text displays provide operators with a view into the operating state of a machine or
process. Operators interact with the control system by using the touch screen.

The PanelView 5310 terminals include these features and capabilities:
• Tightly integrated control and design environment allows information to be shared between the PanelView 5310
terminal and the Logix platforms.
• The Studio 5000® environment provides one point of access for the Studio 5000 View Designer® and Studio 5000
Logix Designer® applications.(1)
• PanelView 5000 terminals are compatible with the following controllers using firmware V27 or later:
ControlLogix 5570 and 5580 controllers and CompactLogix 5370, 5380, and 5480 controllers.
• Supports a maximum of 100 user-defined screens.
• Supports a maximum of 4,000 Logix-based alarms.(1)
• Easily configured screen navigation menu.
• Automatic Diagnostics capability.
• Conformal coating available for all terminal sizes



Catalog Numbers: 2713P-T6CD1, 2713P-T6CD1-B, 2713P-T6CD1-K, 2713P-T7WD1, 2713P-T7WD1-B, 2713P-T7WD1-K, 2713P-T9WD1,
2713P-T9WD1-B, 2713P-T9WD1-K, 2713P-T10CD1, 2713P-T10CD1-B, 2713P-T10CD1-K, 2713P-T12WD1, 2713P-T12WD1-B,
2713P-T12WD1-K
