aluminium die casting machine manufacturers

Cold chamber horizontal die casting machine is mainly used for die casting non-ferrous metals, the working principle is to die casting liquid metal into shape.



Cold Chamber Die Casting Machine For Making Telescope Shell

Cold Chamber Die Casting Machine



Advantages of die casting machine:

1.Adhering to the service mode of "turnkey project", we help customers from machine model selection, logistics and transportation, die casting workshop layout planning, machine installation and debugging,

Operator technical training through - train service.

2.Longhua casting machine stable performance, after years of market development, according to the requirements of different customers, we have greatly improved our machine.When using our die casting machine, you will enjoy a high quality guarantee, because we have made great improvement in the application of so many years, especially the stability performance of the die casting machine of 2000 tons, 2600 tons, 3500 tons is even better than that of many big brands.


 LH series of standard parameter table (200T)

Items

Unit

Specification

Hydraulic Working Pressure

MPa

14

Clamping Force

KN

2000

Space Between Tie Bars

mm

480*480

Tie Bar Diameter

mm

¢85

Die Opening Stroke

mm

380

Injecction Force(intensify)

KN

270

Plunger launch distance

mm

135

Injection position

mm

0  --  140

Plunger Diameter

mm

¢50----¢70

Injection Stroke

mm

350

Casting pressure (intensify)

MPa

112/78/57

Casting Fiange Protrusion

mm

10

Casting Fiange Diameter

mm

110

(40Mpa) Max Casting Area Under 40Mpa

CM2

450

lnjection Weight(Al)

Kg

2.4

Die Height(Min--Max)

mm

200~550

Ejector Force

KN

110

Ejector Steoke

mm

80

Motor Capacity

Kw

15

Machine Dimensions  (L*W*H)

m

5.32*1.5*2.35

Referential Machine Weight For Uplifting

T

7

Oil Tank Capacity

L

600

WE reserve the right to make any technical improvement without further notice



Our honors and certificates:

Longhua Intelligent Die Casting Machine And Oilfield Equipment, New Energy Equipment Project has been awarded successively: State Intellectual Property Office: "37 invention patents, 57 utility model patents", "one national torch project", "two national high-tech product certificates", "standard demonstration unit of foundry machinery industry", "director unit of China Product Quality Association", "credit-abiding enterprise" and "entry and exit". Products exempted from inspection by mouth, Vice President Unit of Anhui Cross-border Electronic Commerce Association and other honors.
