Amorphous Core for Gapless Wideband Constant Inductance Filter Choke

What Is an Amorphous Core for Gapless Wideband Constant Inductance Filter Choke?

An amorphous core for gapless wideband constant inductance filter choke is a type of magnetic component designed for applications where stable inductance is needed across a broad frequency range. These cores are made from iron-based amorphous ribbons and do not require an air gap, making them ideal for high-frequency and high-efficiency applications.

The core material offers:

• High Saturation Flux Density: With a saturation flux density of 1.56 T, it can handle high currents without saturation, making it ideal for power electronics.

• Low Core Loss: This results in less heat generation and improved overall system efficiency, especially important in high-frequency applications.

• Excellent Frequency Characteristics: It maintains stable inductance over a wide frequency range, from low to high frequencies, ensuring reliable performance for filtering and smoothing applications.

• Superior Temperature Stability: Operates efficiently over a wide temperature range from –50°C to +120°C, ensuring long-term reliability and stability in various environmental conditions.

Material Characteristic

Key Features

• High Saturation Flux Density
  With a saturation flux density of 1.56 T, the amorphous core allows for compact designs while maintaining high inductance values, making it ideal for power factor correction circuits.

• Low Core Loss
  Amorphous cores provide low core loss at high frequencies (e.g., under 2–3 W/kg @ 100 kHz), reducing energy wastage and improving system efficiency, which is crucial for power electronics in PFC applications.

• Wide Operating Temperature Range
  These cores can operate efficiently in a wide temperature range from –50°C to +120°C, ensuring reliable performance in industrial and automotive applications.

• High Electrical Resistivity
  The cores exhibit a high electrical resistivity of 130 μΩ·cm, significantly reducing eddy current losses, which is crucial for improving efficiency in high-frequency switching applications.

• Superior Thermal Stability
  The amorphous structure ensures minimal degradation even in high-temperature environments, providing long-term stability and reliability for PFC inductors.

• Low Magnetostriction
  This minimizes mechanical noise and vibration, making them suitable for noise-sensitive applications, such as in medical devices and consumer electronics.

Ideal for Smoothing, Noise Filtering, and Energy Storage Applications

• Switching Mode Power Supplies (SMPS)
  Enhance power conversion efficiency, reduce size, and improve EMI suppression in high-frequency switching power supplies.

• Automotive Audio Systems
  Used for filtering and energy storage in automotive audio systems, ensuring clean power delivery and stable performance.

• Solar Inverters
  Improve DC to AC power conversion, increasing energy utilization efficiency and reducing system losses.

• Energy Storage Inductors
  Ideal for use in energy storage systems, providing smooth energy transfer with minimal loss.

• Industrial Equipment and UPS
  Used in industrial drives, UPS systems, and automation equipment, reducing electromagnetic disturbances and improving system reliability.

Custom Options

Customized sizes, inductance values, and coating types are available. Contact us for technical consultation and design support.

Why Choose Dongguan JH Amorphous

• Precision manufacturing with consistent quality

• Space-saving design optimized for modern electronic systems

• Rapid prototyping and flexible production scalability

• Full compliance with RoHS/REACH environmental regulations

Certificates

Dongguan JH Amorphous, a leading professional one-stop amorphous cores manufacturer.

We offer magnet solutions from design to worry-free after-sales. Let talk about your distinct project now!
