ASR1009-X Overview
The Cisco ASR 1009-X Router is for medium and high-end enterprises with up to 200 Gbps total system bandwidth in a 9-rack-unit (9RU) form
factor. With the ASR 1009-X, you can benefit from best-in-class service performance and network resilience through redundant hardware and
carrier class software.
ASR1009-X Specification
|
Brand
|
Cisco
|
|
Part
number
|
ASR1009-X
|
|
Product
Description
|
Cisco ASR1009-X Chassis
|
|
Default
memory
|
8-GB DRAM RP2 8-GB DRAM RP3
|
|
Number
of SIPs or Ethernet line cards supported
|
3
|
|
Shared
port adapters
|
12 SPA slots
|
|
Ethernet
port adapters
|
6 EPA slots
|
|
Route
processor
|
2 route-processor slots
|
|
Network
interface module
|
No
|
|
Redundancy
|
Hardware: Yes
|
|
ESP
support
|
Cisco ASR 1000 Series
40-Gbps ESP (ASR1000-ESP40), Cisco ASR 1000 Series 100-Gbps ESP
(ASR1000-ESP100), and Cisco ASR 1000 Series 200- Gbps ESP (ASR1000-ESP200)
|
|
ESP
bandwidth
|
40 to 200 Gbps
|
|
External
USB flash memory
|
1-GB USB flash-memory support
|
|
Weight
|
70 kg
|
|
Dimensions
|
437.4 mm x 461.0 mm x 399.3 mm
|
|
Warranty
|
One year
|
|
Lead
time
|
2-3 business days
|
|
Shipment
|
DHL, Fedex, Aramex, EMS or per
request
|
