Audited Supplier New Arrival Multi-Layer Prefabricated Light Steel Structure Temporary Office and Dormitory

New Arrival Multi-Layer Prefabricated Light Steel Structure Temporary Office and Dormitory





Advantages:

1. Mobile and reusable

2. Flexible layout and beautiful appearance of doors and Windows

3. Flexible, durable, economical, etc.

4, fast installation, green, no construction waste.

5, heat insulation, wind, shockproof, moisture-proof, waterproof, leakage proof, safe, fast and convenient to move, flexible combination.

6, the interior is completely decorated, external electricity, built-in air conditioning, electricity, lighting, tables and chairs, can be used immediately

7, beautiful appearance, very personalized, according to their preferences any painting.






Bottom Frame structure 3mm cold rolled steel profiles,
3mm cold formed cross members welded together
Floor 18mm fiber cement board
Floor finishes 1.6mm PVC flooring
Roof Frame structure 3mm cold formed cross members,
corner fitting and steel purlin welded together
Outside 0.426mm galvanized and painted steel plate
Insulation 100mm glass wool
Ceiling 0.5mm steel sheet bottom tile
Corner posts 4.5mm cold rolled steel profile
Wall panel Sandwich panel with 75mm rockwool
Window UPVC sliding widow with screened and burglar bars(800mm/925mm*1100mm,Double glazed)
Door Steel door(950mm*2000mm)
meet CE standard
Electrical system Include 2 external electric supply sockets,1 electricity box,2 wall-sockets,
1 Air-conditioning socket,1 switch,2 fluorescent lamps
Painting Automatic galvanizing and baking paint spray molding
Speciffication Details
External dimensions 6058mm(L)*2438mm(W)*2800mm(H)
Internal dimensions 5858mm(L)*2238mm(W)*2505mm(H)
Technical performance Bottom loads 2.00kn/m2
Roof loads 0.75kn/m2
Wind loads 0.50kn/m2
Seismic rating 8
Fire rating Class A Non-conbustible
Thermal Insulation 0.6w/(sqm.k)
Staked layers 3
Re-assemble times 20+
Life time 15 years
