Australian & Saudi Style Rolling Shutter Door Machine

Australian & Saudi Style Rolling Shutter Door Machine with low noise than normal  Rolling Shutter Door Machine.



Australian & Saudi Style Rolling Shutter Door Machine Drawing,spec and work flow
Main Components of Australian & Saudi Style Rolling Shutter Door Machine
1.Manual Decoiler: one set
Un-powered,Manually control steel coil inner bore shrinkage and stop
Max. feeding width: 500mm, coil ID range 470mm±30mm
Capacity: Max.3Ton

2.Cold Rolling Mills:
Material Thickness:0.4-0.6mm,Material Width:1000mm,
With feeding material guide, body frame made from 450# H type steel by welding,Side wall thcikness: 18mm
Rollers manufactured from 45#, precision machined, hard Chrome Coated
Shafts manufactured from 45#,Diameter=φ70mm,precision machined
Motor Driving,Gear chain transmission, 21 steps to form
Main Motor=5.5KW , Frequency speed control 380V/50Hz/3Ph
Forming speed approx.12m/min

3.Hydraulic Cutting device
Cutter frame made from high quality 20mm steel plate by welding
Post cut, stop to cutting, use the same hydraulic motor drive
hydraulic motor:3.0KW
Hydraulic pressure range: 0-10Mpa
Cutting tool material: Cr12, Heat treatment

4.PLC Control System(Touch screen brand:German Schneider Electric,Inverter brand:Taiwan DELTA,Encoder brand:Japan Koyo)
Control the quantity and cutting length automatically
Combined with: PLC, Inverter, Touch Screen, Encoder, etc
Cut-to-length tolerance≤±2 mm
Control Voltage 24V

5.Exit Rack Un-powered, two units
6.User's manual in English


Features of Australian & Saudi Style Rolling Shutter Door Machine

This Machine is used to produce profile  for door.This product is widely used in many kinds of industrial factory, civilian buildings, and wall board for attached part product. It has advantage of pretty appearance, durable using and so on. It is producted continuously as roll forming machine instead using bending machine to make angel tile saving human resources, lower labor cost.



The complete Australian & Saudi Style Rolling Shutter Door Machine includes decoiler, main machine, computer controlling system and run out tables. Our machines are equipped with a computer controlling system. We simply program the pieces and length we need in the computer and the ridge cap roll forming machine produces it automatically. The machines are easy to operate and running stable.

After-sale Service
1. The warranty of Australian & Saudi Style Rolling Shutter Door Machine is one year after the client receives the machine. Within the one year, we will courier the replacement parts to the client free of charge.
2. We offer technical support for the entire life of our machines.
3. We can send our technicians to install and train the workers in the clients' factories.

Terms of trade
1. Minimum order quantity (MOQ): 1 piece
2. Delivery time: 60 days
3. Port of loading: port of Xiamen
4. Type of payment: T/T
5. Export: Australia, UK, Ireland, Mexico, Brazil ,Israel ,Dubai, Russia ,India, Taiwan, Singapore,  Malaysia ,Thailand, Philippines, Myanmar ,Vietnam, South Africa, Mozambique, Zambia, Zimbabwe, Nigeria, Egypt, Sudan, etc.
