Auto 12v/24v/48v 60A Solar System Charge MPPT Controller

Specialized in solar design & sales for wholesale and DIY customers

See our 4.9-Star Google Reviews

Check out our featured Customer Installs

LED or LCD display//MPTT


  • SampleAvailable


Cooperator: Guangzhou Sunnysky Solar Equipment Co., Ltd. Sunnysky solar MPPT controller is its own research and development, their own production of a new generation of intelligent MPPT solar controller, can automatically identify 12V24V36V48V voltage.

Features:

1、Display real-time power generation and current;

2、Display the daily power generation curve and current curve;

3、Chinese and English, multi-function LCD screen and operation menu;

4、Display fault records, to facilitate customer troubleshooting in a timely manner;

5、Support lead-acid batteries, colloidal batteries and lithium batteries;

6、Intelligent maximum power point tracking technology increases efficiency 25%~30%;

7、Battery temperature sensor (BTS) automatically provides temperature compensation;

8、Perfect protection function;

9、Tracking accuracy of more than 99%;

10、Ultra-fast tracking speed, tracking 1 times per second.


Model TYC-20IR TYC-30IR TYC-40IR TYC-50IR TYC-60IR
Rated voltage 12/24/48V Auto
Rated current 20A 30A 40A 50A 60A
Maximum protection current 22A 32A 42A 52A 62A
Battery voltage identification range 12V(DC9-DC15V);      24V(DC18-DC30V);      48V(DC36-DC60V)
MPPT Operating voltage range 12V (DC18V~DC150V);24V(DC34V~DC150V); 48V(DC65V-150V)
Maximum PV input power 12V280W 420W 570W 700W 900W
24V550W 840W 1130W 1400W 1700W
48V1100W 1650W 2270W 2800W 3400W
PV input low voltage protection point 12V:DC16V;      24V:DC30V;      48V:DC60V
PV input low pressure recovery point 12V:DC18V;      24V:DC34V;      48V:DC65V
Limit input voltage DC160V
PV input overvoltage protection point DC150V
PV input overvoltage recovery point DC145V
Static power consumption ≤2 W
Machine efficiency ≥9 6 . 5 %≤9 9 %
PV module utilization ≤9 9 %
Float voltage (can be customized) 12V:13.75V;      24V:27.5V;      48V:55V
Average charge voltage(can be customized) 12V:14.2V;      24V:28.4V;      48V:56.8V
Recommended PV module voltage 12V:(18V-60V);      24V:(36V-72V);      48V:(72V-144V)
Temperature compensation -3mV℃/2V
Temperature protection 90℃
Temperature rise protection 8 5 ° C or more to reduce power output
Protective function

PV array short circuit, overvoltage, overcurrent reverse polarity

 protection, battery overcharge, reverse protection

Working temperature -35℃ to +55℃
Humidity 0~90%RH (Not condensation)
Altitude 0~3000m
Security Level CE、PSE、FCC、EMC
Mechanical protection class IP21
Colour Apple green (customizable)
Product Size 218*154*65MM 250*180*75MM
Weight 2KG 3KG
