Standards
GB/T 6672、GB/T 451.3、GB/T 6547、ISO 4593、ISO 534、ISO 3034、ASTM D645、ASTM D374、ASTM D1777、ASTM F2251、TAPPI T411、DIN 53105、DIN 53353、JIS K6250、JIS K6328、JIS K6783、JIS Z1702、BS 3983、BS 4817
Features
High precision (0.1μm), digital display, stable, easy to operate.
Measuring mode: manual and automatic.
Single point and multiple points measurement.
LCD display, real time display of max, min, average and current values.
With built-in printer, can print test report.
|
Test range
|
0~3mm
|
|
Test resolution
|
0.1μm
|
|
Number of test points
|
0~30 points
|
|
Space of sampling
|
0~1000mm
|
|
Measure force
|
0.5N
|
|
Measure head size
|
Φ5mm (can customize)
|
|
Working Temperature
|
0~40℃
|
|
Power
|
1000W
|
|
Power supply
|
AC220V 50Hz
|
|
Instrumentsize
|
380mm ×360mm × 720mm
|
|
Weight
|
25kg
|
