Beiben 4x2 tow truck for sale favorable price
Tractor Truck
|
Driving type: 4X2 Based on Benz Design platform
|
Cabin
|
BENZ technology cab, single sleeper, Manual Window, with air-conditioning
|
Engine
|
Diesel, 4-stoke Direct injection,6-cylinder in line, radiator, Turbo-charging.
|
Model:
|
WP10, 12
|
European technology WEICHAI
|
|
MAX Horse power:
|
340-420HP
|
Gear box
|
|
Applied American technology
|
|
Model:
|
FAST (Fuller technology)
|
|
Speed:
|
9speed,1reverse
|
Axle(front/rear)
|
Front axle
|
Benz technology 5.5ton front axle
|
Tandem
|
Benz strengthened axle (punching-welding axle housing)
|
(Driving axle)
|
single reduction driving axle, inter-wheel differential lock
|
Clutch
|
D430 diaphragm type
|
Brake
|
Service brake: Double circuit pneumatic brake
|
|
Parking brake: Spring-Power drum brake
|
|
|
Steering
|
TAS85, driver sit at the left hand side (right hand is optional)
|
Frame
|
300mmx80mmx 8mm (inner: 275mm*70mm*5 mm )
|
Tyre
|
6+1 spare tyre with wheel
|
|
12.00-20 nylon tire
|
Suspension system: Leaf spring type
|
|
Front/Rear
|
9/13
|
Overall dimension(mm): 5995x2500x3180(Length x width x height)
|
Wheelbase
|
3500mm
|
Track:
|
|
|
Front/Rear
|
2045/1800
|
|
Approach/Departure angle
|
16/40
|
|
Front /Rear overhang
|
1410/1085
|
|
Max speed
|
110km/h
|
Kerb weight:
|
6800kg
|
Diesel tank
|
300L
|
