| STEYER, MAN, BENZ design platform. INTERNATIONAL QUALITY STANDARD |
| Cabin |
air deflector,air-condition ,single or double sleeper, USB application, electric window lifter,GPRS management system. MAN/STEYER cabin |
| Drive type |
Left hand / right hand, 4x2,6x2,6x4,8x4,6x6. |
| Engine : WEICHA I(WP series ,WD series) CUMMINS series: |
| Type |
Diesel 4-stroke direct injection engine, 6-cylinder in line with water cooling, turbo-charging& inter cooling. |
| Number of cylinder |
Inline six-cylinder |
BOSCH oil pump |
| Displacement |
5.762L, 11.596L |
|
| Emission |
Euro 2,3,4 |
|
| Max torque (kg.m/rpm) |
1 070NM-2000NM@1400-1600rpm |
| Cl u tch |
| Type |
430 diaphragm construction |
| Single-plate dry cluth,mechanically operating with air assisted |
| Gear box ,Transmission |
| Model |
FAST FULLER(recommendation), ZF 8098, |
| Type |
9,10,12,16 speeds AS ( Automatic Synchronizer ) |
| Gear box |
Mechanical form , Remote control device |
| Front axle |
| Type |
STYER / HANDE, |
| Permissble load |
Kg /axle |
65 00 kg,7500kg |
| Rear driving axle |
| Model |
STYER / HANDE driving axle |
| Type |
Pressed axle housing,single/double reduction with planetary wheel reduction. |
| Permissble load |
Kg /axle |
1 3000kg,16 000 kg |
| Track |
1800/1860 |
| Transmission ratio |
4.42 4.80 5.73 6.72 7.49 8.40 9.94 |
| Tyre : |
| |
Bias/Radial TYRE 315/80R22.5 / 12.00R20 |
| Braking sytstem |
| Brake |
|
ABS,ASR |
| Service brake |
Dual circuit pneumatic brake |
| Parking brake |
Spring energy,compressed air operating on rear wheels |
| Hanging |
| Type |
FR/RR |
Spring plate,Lug/Multi-leaf spring |
| Electric equipment |
| Operating voltage |
24v,negative grounded |
| Battery voltage/capacity |
12v/135A,165A |
| Turning technology |
ZF8098 hydraulic pressure steering system |
| Oil Tank : 38 0L -1000L |
| Dimension of King pin(5th wheel): 50(2’’),90(3.5’’). |
| Other option: PTO, more than 20 colors’ surface, strengthen leaf spring.mainly as your requests. |
