Logging semi-trailers in confirmity with regulations,and matching specifi conditions encountered by foresters. Bogie with reinforcedaxles, 30 to 50 Tons loading capacity. Width capacity RANGING from 2.5 to 3.5meters.
We can provide :
"GABON TYPE" log trailers with 2 x 3.10 or 3.5 m wide bunks,mounted on JOST turntables. 1 fixe stake and 1 hinged stake.
"CAMEROON TYPE" log trailers with 2.5 bunks with adjustableholding wedges.
"MALAYSIAN TYPE" log trailers with 2 x 3.10 bunks mounted onJOST turntables. 2 hinged stakes.
Fifth wheel coupling is also available on request
| Wheel base (mm)
|
4100+1450
|
| Curb weight kg
|
12400
|
| Engine
|
Model
|
WD12.375,water-cooled,four strokes,6 cylinders straight in line,turbocharged,
|
| Power, max kw/rpm
|
280/2200
|
| Emission
|
EUROII
|
| Clutch
|
Model
|
Φ430, Single dry frictional disc,Hydraulic boosting
|
| Gearbox
|
Model
|
12JS160T
|
| Brake system
|
Service brake
|
Brake gap can be adjusted automatically, double circulation air brake system
|
| Assistant brake
|
Engine exhaust brake
|
| Park brake
|
Potential springs pressing on middle and rear wheels
|
| Steering system
|
Model
|
ZF8098,whole circulation in ball type, hydraulic boosting
|
| Frame
|
Fish belly shape, variable width, variable sections
|
| Front axle (Mercedes Benz Technology)
|
Double-shoe pneumatic brake, non-driving steering axle
|
| Middle and Rear axle (Mercedes Benz Technology)
|
Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle
Ratio: 6.7
|
| Tyre
|
Radial 12.00R24
|
| Electrical system
|
Battery
|
2X12V/135Ah
|
| Generator
|
28V-35A
|
| Starter
|
5.4Kw/24V
|
| Cab
|
Short cab
color:White color with strip
Full steel skeleton structure, covered with double layer steel plate;Can be tipped forwardly;
Seat: shock absorption seat for the driver
With inner A/C
|
| Others
|
With Tropical thermostat
Exhaust pipe upwards
With rear trailer brake system
Eight U-bolt (Four U-Bolt each side)
With differential between axle and wheel
Oil tank: 400L+300L
With Desert air filter
|
