Driving type
|
4x4
|
Dimension(Lx W x H) (unloaded) (mm)
|
8826x2500x3215
|
Inner dimension (mm)
|
6500x2300x600
|
Approaching angle/Departure angle(°)
|
30/26
|
Overhang(front/rear) (mm)
|
1410/2616
|
Wheel base (mm)
|
4800
|
Max speed (km/h)
|
90
|
Curb weight (kg)
|
7980
|
Engine Styr technology, made in China
|
Model (WP10.300N)
|
WEICHAI Diesel engine, water-cooled, four strokes, 6 cylinders in line, turbocharged, directly injection
|
Displacement (L)
|
9.726/Diesel
|
Bore x stroke (mm)
|
126/130
|
Max power (kw/rpm)
|
221/2200
|
Max torque (Nm/rpm)
|
1390/1200-1500
|
Emission
|
EURO III
|
Clutch
|
Model
|
Single dry frictional disc, Hydraulic boosting
|
Gearbox
|
Model
|
RT11509C, mechanism,9gears,1reverse gear, manual
|
Brake system
|
Service brake
|
Double circulation air brake system
|
Assistant brake
|
Engine exhaust brake
|
Park brake
|
Potential springs pressing on middle and rear wheels
|
Steering system
(ZF company)
|
Model
|
TAS85,whole circulation in ball, hydraulic booster
|
Frame
|
Fish belly, shape, variable width, variable sections, side beam structure
|
Front axle
(Mercedes Benz)
|
Double-shoe pneumatic brake, non-driving steering axle
|
Middle and Rear axle
(Mercedes Benz Technology)
|
Double-shoe pneumatic brake, casting, double reduction driving axle
|
Tyre
|
12.00-20
|
Electrical system
|
Battery
|
2X12V/135Ah
|
Generator
|
28V-35A
|
Starter
|
5.4Kw/24V
|
Cab
|
Full steel skeleton structure, covered with double layer steel plate; Can be tipped forwardly, short cabin without sleeper
|
