| Cab |
middle length cab, made by full steel material, anti-crash performance can be ensured by double hollow chamber structure. Inner A/C |
| Kerb weight |
8800kg |
| Gross Vehicle Weight |
25000kg |
| Wheelbase(mm) |
3300+1350 |
| Engine |
Brand: |
WEICHAI |
| Model: |
WP10.336 |
WP10.375 |
WP12.375 |
WP10.380E32 |
| Power (kw/hp): |
247/336 |
276/375 |
276/375 |
280/380 |
| Max torque(N.m/rpm): |
1250/1200-1600 |
1460/1200-1600 |
1630/1200-1200-1500 |
1600/1800 |
| |
Displacement (L): |
9.726 |
9.726 |
11.596 |
9.726 |
| Transmission |
Brand:FAST GEAR Model:9JS150A 9-forward &1-reverse gears |
| Clutch |
Single dry frictional disc,Hydraulic boosting |
| Steering |
Model:ZJ120D |
| Brake |
Service brake:Brake gap can be adjusted automatically, double circulation air brake system Assistant brake:Engine exhaust brake Park brake:Potential springs pressing on middle and rear wheels |
|
|
| Frame |
Fish belly shape,variable width, variable section side beam structure |
| Front axle (Mercedes Benz Technology) |
7.5 ton non-driving steering axle |
| Middle and Rear axle (Mercedes Benz Technology) |
485Single reduction driving axle |
| Tyre |
12.00R20 |
| Fuel tanker capacity L |
400 |
| Speed Ratio |
4.625 |
| Leaf spring quantity |
3/4 |
