Description
1.Well wear resistance
2.Size: dia 0.5mm-30mm,overal length:50mm to 200mm
3.No. of flute: 2 flutes
4.Work piece:copper & aluminium alloy,general steel,stainless steel,
   titanium alloy,hest-resistant super alloy,hardened steel,wood,dfrp
5.Coating: AlTiN,etc


Applications
End mill and drill and carbide cutting tools manufacturer
1.Suitable for Copper, Cast Iron, Carbon steel, Tool steel, Mould steel, Die steel, Stainless steel, Plastic, Arcylic, etc.
2.Applicated for Aerospace, transportation, Medical equipment, military manufacturing, mould development, apparatus and instrument, etc



Carbide Rod Grade

Type Material Co Grain size Flexural Strength
HRC45 YG10X(Zhuzhou) 10% 0.7um 3320N/mm2
HRC55 YG10.2&WF25(Taiwan)
10% 0.6um 4000N/mm2
HRC65 H10F(Sweden) 10% 0.5um 4300N/mm2


Coating Grade

Type Hardness(HV) Thickness(UM) Oxidation Temp Friction Coefficient Color
AITiN 3200 2.5-3 900 0.3 Black
TiSiN 3600 3 1000 0.45 Copper
nACo 42(GPA) 3 1200 0.4 Blue


Name
Solid Carbide End Mill
Material
Tungsten Carbide
Flutes
2/4/6 Flute
Hardness
HRC45, 55, 65
Helix Angle
30° 35° 45°30° 35° 45°AlTiN, NACO BLUE, NACO BLACK, TiN etc.
Coating
AlTiN, NACO BLUE, NACO BLACK, TiN etc.
HRC45, 55, 60, 65, 68
Flat end mill, ball nose end mill, corner radius end mill and aluminium processing end mill
Size
Dia: 1-20 mm, Overal Length:50-150mm
Smooth Finish
Highly Polished
Feature
Excellent chip evacuation


Our Machine
We are the manufacture and wholesaler of cnc cutting tools more than 16 years,manufacture machines
are Anca,Deckel,Walter.
  - Anca machine for produce small diameter end mills
  - Deckel machine for produce big diameter end mills
  - Non-standard cutters made in Walter machine

Product main Features
1. Competitive pricing and quality of carbide endmill cutters
2. Made by world latest 5AXIS CNC tools grinder, promise the quality and precision of cutter.
3. Each end mill is inspected by measuring and inspected machine.






ZONG




Packaging & Shipping

CNC Cutting Tools Brazed Carbide End Mill, solid carbide end mills
In plastic box, then in cartons, or as customers' requirement
Delivery:  Genreally within 7days after confirming the order, depending on quantity
Shipping: By express(Door to Door) or by air




Buyer Feedback







Exhibition



FAQ

Q: Are you trading company or manufacturer ?

A: We are end mill factory.Our factory is located in zhuzhou City, Hunan Province. Welcome to visit our factory!

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: No, we could not offer the sample for free, but we can give you a big discount for big order

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
