Advantages for this barcode scanner 2 in one
1. Both wired USB and wireless Bluetooth which comes with flash memory.
2. PNPUSB2.0 without any driver, can directly connect to PC/tablets/phones which support USB host or USB OTG.
3. Perfectly support various versions Microsoft, IOS, Android OS.
For iphone and ipad user, Please double-click the scanner button to activate the iPad/ iPhone keyboard once the pairing process has been successfully completed.
4. Support HID virtual keyboard scanning, the usercan read in the barcodes in their ERP system without any change.
5. Professional technical support team will help you solve any usage problem.
|
Material
|
ABS+TPU
|
|
Scan speed:
|
200 scan/sec
|
|
Color
|
White + Black
|
|
Power supply
|
Built-in rechargeable 1600mA.H lithium battery
|
|
Bluetooth
|
Bluetooth class 2.0, Version +EDR
|
|
Processor
|
ARM 7 72MHz
|
|
Interfaces Supported Multiple Interface with
|
SB, RS232, PS2 Keyboard
|
|
Support OS
|
Microsoft Windows XP/7.0/8.0, Mobile6/Wince, Android, IOS
|
|
Light Source (Laser)
|
Laser LED 650+/-20nm
|
|
Sensor
|
2500 pixels
|
|
Decode Capability
|
Coda bar, Code 11, Code 93, MSI, Code 128, UCC/EAN-128, Code 39, EAN-8,
|
|
EAN-13, UPC-A, ISBN, Industrial 25, Interleaved 25, Standard 25, 2/5 Matrix
|
|
Resolution
|
5mil
|
|
Nominal Working
|
Distance 6~30cm
|
|
Decode
|
Rate 200 decodes per second
|
|
Scan width
|
30mm=Scanner Window
|
|
Decode mode
|
Single-Line Aiming
|
|
Single-Line Aiming
|
Auto off mode / Manual mode / Automatic induction mode
|
|
Print Contrast
|
Minimum 30%25
|
|
Scan angles
|
Roll 30° Pitch 75° Yaw65°
|
|
Cylinder Horizontal
|
Scan Diameter 35mm
|
|
Indication Beeper
|
Beeper, LED
|
|
Radio Range
|
10m Visual range
|
|
Power
|
Voltage DC 5V Standby Current 35mA
|
|
Operating current 60mAh
|
|
Operating Temp.
|
0 to 50°C / 32 to 122°F
|
|
Storage Temp.
|
0 to 50°C / 32 to 122°F
|
|
Operating Humidity
|
20-85%25 ( non-condensing )
|
|
Storage Humidity
|
20-85%25 ( non-condensing )
|
|
Drop Specifications
|
Free fall of 1.5m air drop
|
|
Accessories
|
Lithium battery, Charger, Data lines, English user manual
|
|
Weight
|
0.4kgs
|
|
Size:
|
167mm (L) x 70mm (W) x85.5 (H) mm
|
