Boom Length 60m 10t QTZ125P(6015) Flat Head Tower Crane

QTZ125P(6015) Hydraulic lifting Flat head construction tower crane, topless type, max load 10t, boom length 60m with tip load 1.5t. Quality is high and price is favorable. Topless type is more convenient and applicable for multiple tower cranes operation.



QTZ125P(6015)---Boom Length 60m 10t QTZ125P(6015) Flat Head Tower Crane

1.Flat top tower crane/hydraulic lifting tower crane/flat head tower crane/topless construction tower crane

2. 10t max load, 60m working radius with tip load 1.5t.

3. China-made high quality tower crane, China good tower crane manufacturers with best price.

4. high efficiency, CE, ISO, GOST certificates, oversea service available

loading capacity of PQTZ125(6015)  tower crane

Radius(m)

2.5-12.78

13

16

18

20

23

23.97

25

30

33

35

36.32

38

43

45

48

50

53

55

58

60

a=2

5.00

4.72

3.80

3.38

3.14

3.00

2.83

2.41

2.27

2.08

1.96

1.80

1.71

1.58

1.50

a=4

10.00

9.68

7.83

6.87

6.10

5.20

5.00

Mechanismspecification of QTZ40 (TC4808) tower crane

The lifting moment

1250KN.M

The max loading capacity

10t

The jib length

60m

The trolleying radius

2.5-60(m)

The tip load

1.5t

Lifting height

Stationary

50m

Attached

180m

Hoisting

2 fall

4 fall



37 (KW)

m/min

80

40

40

20

t

2.5

5

5

10

Trolleying

44/22 m/min

4.5/3(KW)

Slewing

0-0.74 r/min

95N.M*2

Climbing

0.6 m/min

7.5KW

Main supply

~380V 50HZ/440V 60HZ

MOQ

1 set, the more you buy, the cheaper it is

Main chord

135*12(mm)

Mast section

1.833*1.833*2.5(m)

Material

Q345B manganese steel

Payment terms

30% T/T in advance, 70% balance payment before shipment date.

Delivery time

Within 20 days after receiving the customer’s 30% T/T advanced payment.

Abroad markets

The Middle East Regions, Southeast Asia, Africa, Russia, etc

Package

Nude in 40” HQ container (6*40”/10*40” HQ containers for the stationary height (50m) of (chip/standard mast section) the PQTZ125 (6015) tower crane.)

Certificate

ISO9001

Warranty

12 months from the bill date.

Trade term

EXW, FOB(Qingdao), CIF

After-sales service

Engineer is ready to install, test and maintain the tower crane and train the workers
