C6800-48P-SFP-XL Overview
C6800-48P-SFP-XL is Cisco Catalyst 6800 48-port 1GE fiber module with integrated DFC4XL. This C6800-48P-SFP-XL is similar with the C6800-48P-SFP-XL=. The C6800-48P-SFP-XL= is a spare one.
C6800-48P-SFP-XL Specification
|
Brand
|
Cisco
|
|
Part
number
|
C6800-48P-SFP-XL
|
|
Product
Description
|
C6k 48-port 1GE
Mod:fabric-enabled with DFC4XL
|
|
Product
Type
|
6800 Series 1 Gigabit Modules
|
|
Port
connector type
|
LC (optical) or RJ-45 (copper)
depending on the SFP transceiver installed
|
|
Ports/Interface/
Connectors
|
48 port; 1000BASE-SX, LX/LH,
-ZX, -T; 1000BASE-CWDM; LC connecter
|
|
Backplane
connection
|
Connects to the switch fabric
using dual full-duplex 20-Gbps switch fabric channels (40 Gbps total)
|
|
Supervisor
engine
|
Compatible with Supervisor
Engine 2T and Supervisor Engine 2TXL.
|
|
Chassis/slot
support:
|
Can occupy slots 1-2 and 5-7 in
C6807-XL chassis. Can occupy any slots in Cisco Catalyst 6503E, 6504E,6506E,
6509E, and 6509-V-E. Can occupy slots 1-6 and 9-13 in a Cisco Catalyst
6513-E.
|
Distributed
forwarding
and performance
|
Comes equipped with DFC4XL
daughter cards, delivering optimal performance up to a sustained 60 Mpps
forL2, IPv4 and MPLS forwarding and 30 Mpps for IPv6 forwarding.
|
|
Maximum
Frame Size
|
Up to 9216 bytes/frame
|
|
Scheduler
|
Deficit Weighted Round Robin
(DWRR)
|
|
Onboard
Memory
|
1GB Default
|
|
Power
Requirements
|
334.44 and 339.44 Watts
respectively
|
|
Dimensions
|
3.0 x 35.6 x 40.6 cm
|
|
Weight
|
3.95 kg
|
|
Warranty
|
One year
|
|
Lead
time
|
2-3 business days
|
|
Shipment
|
DHL, Fedex, Aramex, EMS or per
request
|
