Technical
Specifications
|
|
|
Slot Provided
|
|
|
Type
|
Expansion
slot
|
|
Total Qty
|
1
|
|
Free Qty
|
1
|
|
Interface
Provided
|
|
|
Qty
|
48
|
|
Type
|
1000Base-T
|
|
Comments
|
PoE+
|
|
Connector Type
|
RJ-45
|
|
Networking
|
|
|
Type
|
Switch
|
|
Remote Management Protocol
|
CLI,
NETCONF, RESTCONF, RMON 1, RMON 2, SNMP 1, SNMP 2c, SNMP 3
|
|
Compliant Standards
|
IEEE
802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE
802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE
802.3u, IEEE 802.3x
|
|
Status Indicators
|
Status
|
|
Ports Qty
|
24
|
|
Features
|
16MB
packet buffer, 3 fans, 802.1x authentication, Access Control List (ACL)
support, Cisco StackPower technology, Cisco StackWise-480 technology, Control
plane protection (CoPP), Flexible NetFlow (FNF), FTP client, Full duplex
mode, Integrated Wireshark, Management Information Base (MIB), Private VLAN,
Quality of Service (QoS), Remote Switch Port Analyzer (RSPAN),
Source-Specific Multicast (SSM), Spanning Tree Protocol (STP) support,
Trunking, VLAN Double Tagging (Q-in-Q), Weighted Random Early Detection
(WRED)
|
|
Routing Protocol
|
IGMP,
IS-IS, OSPF, OSPFv3, PIM-SM, PIM-SSM, Policy-based routing (PBR), RIP-1,
RIP-2, RIPng, VRRP
|
|
MAC Address Table Size
|
32000
entries
|
|
Stackable
|
Stackable
|
|
Subcategory
|
Network
hubs and switches
|
|
Power Over Ethernet (PoE)
|
PoE+
|
|
Advanced Switching
|
Layer
3
|
|
Manageable
|
Yes
|
|
Form Factor
|
Rack-mountable
|
|
Jumbo Frame Support
|
9198
bytes
|
|
Subtype
|
Gigabit
Ethernet
|
|
PoE Budget
|
445
W
|
|
Miscellaneous
|
|
|
Compliant Standards
|
AS/NZS
3548 Class A, BSMI Class A, CAN/CSA C22.2 No. 60950-1, CCC, CISPR 22 Class A,
CISPR 24, EN 300386, EN 55022 Class A, EN 60950-1, EN 61000-3-2, EN
61000-3-3, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN
61000-4-6, EN 61000-6-1, EN50082-1, EN55024, FCC CFR47 Part 15 A, ICES-003
Class A, IEC 60950-1, RoHS 5/6, TVCN 7317, UL 60950-1, VCCI Class A, VCCI
V-3/2009 Class A
|
|
MTBF
|
299,000
hours
|
|
Height (Rack Units)
|
1
|
|
Encryption Algorithm
|
128-bit
AES
|
|
Color Category
|
Gray
|
|
Environmental
Parameters
|
|
|
Min Operating Temperature
|
23
°F
|
|
Max Operating Temperature
|
113
°F
|
|
Humidity Range Operating
|
5
- 90% (non-condensing)
|
|
Min Storage Temperature
|
158
°F
|
|
Max Storage Temperature
|
104
°F
|
|
Humidity Range Storage
|
5
- 90% (non-condensing)
|
|
Header
|
|
|
Compatibility
|
PC
|
|
Manufacturer
|
Cisco
Systems
|
|
Packaged Quantity
|
1
|
|
Product Line
|
Cisco
Catalyst
|
|
Model No
|
C9300-24P-E
|
|
Brand
|
Cisco
|
|
Edition
|
Network
Essentials
|
|
Power Device
|
|
|
Frequency Required
|
50
- 60 Hz
|
|
Power Provided
|
715
Watt
|
|
Installed Qty
|
1
|
|
Max Supported Qty
|
2
|
|
Nominal Voltage
|
AC
120/230 V
|
|
Power Redundancy
|
Optional
|
|
Type
|
Internal
power supply
|
|
Hot-Plug
|
Hot-plug
|
|
Service
|
|
|
Support Details Type
|
Technical
support
|
|
Support Details Service Included
|
Consulting
|
|
Support Details Full Contract Period
|
90
days
|
|
System
Requirements
|
|
|
Min Operating System
|
Cisco
IOS Universal
|
|
Dimensions
& Weight
|
|
|
Width
|
17.5
in
|
|
Depth
|
17.5
in
|
|
Height
|
1.7
in
|
|
Weight
|
16.31
lbs
|
|
|
|
Service &
Support
|
|
|
Type
|
Limited
lifetime warranty
|
|
Capacity
|
|
|
Type
|
VLAN
IDs
|
|
Value
|
4000
|
|
Flash Memory
|
|
|
Installed Size
|
16
GB
|
|
Performance
|
|
|
Type
|
Switching
capacity
|
|
Value
|
128
Gbps
|
|
Ports
|
|
|
Qty
|
24
|
|
Type
|
10/100/1000
(PoE+)
|
|
RAM
|
|
|
Installed Size
|
8
GB
|
|
Service &
Support Details
|
|
|
Response Time
|
Next
business day
|
