General
|
|
|
Model No
|
C9300-48U-A
|
|
Device Type
|
Switch
- 48 ports - L3 - managed - stackable
|
|
Enclosure Type
|
Rack-mountable
1U
|
|
Subtype
|
Gigabit
Ethernet
|
|
Ports
|
48
x 10/100/1000 (UPOE)
|
|
Power Over Ethernet (PoE)
|
UPOE
|
|
PoE Budget
|
822
W
|
|
Performance
|
Switching
capacity: 128 Gbps ¦ Stacking bandwidth: 480 Gbps ¦ Forwarding rate: 190.48
Mpps
|
|
Capacity
|
IPv4
routing table entries: 32000 ¦ IPv6 routing table entries: 16000 ¦ Flexible
NetFlow entries: 64000 ¦ VLAN IDs: 4000 ¦ Switched virtual interfaces (SVIs):
2000
|
|
MAC Address Table Size
|
32000
entries
|
|
Jumbo Frame Support
|
9198
bytes
|
|
Routing Protocol
|
OSPF,
IS-IS, RIP-1, RIP-2, BGP, EIGRP, HSRP, IGMP, VRRP, PIM-SM, OSPFv3, PIM-SSM,
MSDP, policy-based routing (PBR), RIPng
|
|
Remote Management Protocol
|
SNMP
1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF
|
|
Encryption Algorithm
|
128-bit
AES
|
|
Features
|
DHCP
support, trunking, Syslog support, full duplex mode, Stateful switchover
(SSO), Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early
Detection (WRED), Spanning Tree Protocol (STP) support, Access Control List
(ACL) support, Quality of Service (QoS), Non-Stop Routing (NSR), Remote
Switch Port Analyzer (RSPAN), Management Information Base (MIB), Cisco
StackWise-480 technology, Cisco StackPower technology, Flexible NetFlow
(FNF), Multicast Source Discovery Protocol (MSDP), 802.1x authentication,
16MB packet buffer, FTP client, MACsec support, 3 fans, Control plane
protection (CoPP), Virtual Extensible LAN (VXLAN), Application Visibility and
Control (AVC), Source-Specific Multicast (SSM), integrated Wireshark, VLAN
Double Tagging (Q-in-Q), Ethernet over MPLS (EoMPLS), Hierarchical Virtual
Private LAN Service (H-VPLS), Private VLAN, Layer 3 VPN (L3VPN) support,
Encapsulated Remote SPAN (ERSPAN), Security Group Tag (SGT) caching, Security
Group Access Control List (SGACL), IT Service Management (ITSM) integration,
third-party IP Address Management (IPAM) integration
|
|
Compliant Standards
|
IEEE
802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE
802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE
802.1s, IEEE 802.3at
|
|
RAM
|
8
GB
|
|
Flash Memory
|
16
GB
|
|
Status Indicators
|
Status
|
|
Expansion /
Connectivity
|
|
|
Interfaces
|
48
x 1000Base-T RJ-45 UPOE ¦ 1 x USB 2.0
|
|
Expansion Slots
|
1
(total) / 1 (free) x expansion slot
|
|
Power
|
|
|
Power Device
|
Internal
power supply - hot-plug
|
|
Installed Qty
|
1
(installed) / 2 (max)
|
|
Power Redundancy
|
Optional
|
|
Power Provided
|
1100
Watt
|
|
Voltage Required
|
AC
120/230 V (50 - 60 Hz)
|
|
Warranty
|
1
year
|
|
Lead time
|
2-3
business days
|
|
Shipment
|
DHL,
Fedex, Aramex, EMS or per request
|
