Manufacturers Caterpillar Hydraulic Filter 1R-0735, 1R-0735
Cross Reference:
Fleetguard HF6376, Donaldson P530523
The 1R-0735 Parameter：
|
Part Number
|
1R-0735,1R0735
|
|
Parts Name
|
Hydraulic Filter
|
|
Brand
|
Caterpillar
|
|
Overall Height
|
178.00 mm
|
|
Outer Diameter
|
129.00 mm
|
|
Inner Diameter
|
85.00 mm
|
|
Efficiency Rating
|
Standard Efficiency
|
The 1R-0735 Advantage：
Cat Hydraulic Filter provide the best protection from contaminates and abrasives by keeping them from wearing down the tight tolerances within the high pressure hydraulic system. Cleanliness is the key to maintaining proper lubrication of your sensitive hydraulic system.
The 1R-0735 has four attributes:
1. Acrylic beads prevent bunching
2. Spiral roving provides greater pleat stability and maximum dirt holding capability
3. Nylon center tube prevents metal contamination
4. Molded end caps prevent leaks
The Technology of Spiral Roving and Acrylic beads:
The 1R-0735 Application：
|
Compatible Models
|
|
PIPELAYERS
578
|
|
TTT
D6R II D6R, D8R II D8R D10N, D6H XL D6M D9R, D6H XR D8N, D6H
|
|
SKIDDERS
527CA, 527GR, 525B, 545
|
|
TSKD
527
|
|
WHEEL LOADERS
910F
|
|
IT
IT12B
|
|
TRACK TYPE TRACTORS
D9R, D6R, D6RIIXL, D8RII, D6RIILGP, D6RII, D8RLRC, D6HIIXL, D6RLGP, D6RXL, D6MLGP, D6RIIXW, D9RLRC, D6NLGP, D5NXL
|
|
PIPE
583R
|
|
LARGE MINING PRODUCTS
5230
|
