Caterpillar spare parts 094-0616 0940616 for E317

CATERPILLAR travel bearing 094-0616 0940616

094-0616 BEARING Caterpillar parts fit: E311C, E315C, E315D L, E318B, E319C, E320B, E320C, E320D, E321C, E322, E322B, E323D L, E200B



CATERPILLAR excavator travel bearing 094-0616

P/N 094-0616 Material:
GCR15
i/d mm
O/D
mm
H mm
Brand: ZHZB
Precision
P0 , P6 , P5
Structure:
Radial needle roller bearings

Product features:
1. Special bearing for excavator travel gearbox
2. It can bear the load from both axial and radial at the same time
3. High-strength high-quality steel
4. Smooth rotation and low noise
5. Compared with other companies' final drive bearings, the service life is increased by 50%
Our advantage:

100% factory quality inspection;
Minimum order quantity: 1;
Faster delivery efficiency;
Higher cost performance;
Have a mature production line so that we can customize according to the samples or drawings provided by customers;
Professional manufacturer of final drive bearings for excavators. Have many years of manufacturing experience

Production Process






Product Photos

094-0616 0940616CATERPILLAR 094-0616 0940616Bearing 094-0616 0940616



Any other parts for the travel gearbox system you need , pls search from below picture and form list then mark to me , we will quote to you.

CATERPILLAR parts

Pos.

Part No

Qty

Parts name

Comments

1.

7Y-1434

[1]

SPACER (40X69.5X6-MM THK)



2.

096-1773 B

[1]

SHIM (0.15-MM THK)





096-1774 B

[1]

SHIM (0.3-MM THK)





096-1775 B

[1]

SHIM (0.4-MM THK)





096-1776 B

[1]

SHIM (0.5-MM THK)





096-1777 B

[1]

SHIM (0.6-MM THK)





096-1778 B

[1]

SHIM (0.7-MM THK)





096-1779 B

[1]

SHIM (0.8-MM THK)





096-1780 B

[1]

SHIM (1-MM THK)





096-1781 B

[1]

SHIM (1.6-MM THK)



3.

148-4716

[1]

HOUSING-MOTOR



4.

114-1497

[1]

SEAL GP-DUO-CONE



5.

168-8451

[2]

BALL BEARING



6.

114-1486

[1]

HOUSING



7.

114-1539

[6]

PIN-DOWEL



8.

148-4715

[1]

GEAR-COUPLING (55-TEETH)



9.

6D-0692

[1]

SEAL-O-RING



10.

7Y-1433

[1]

CARRIER



11.

6V-3303 M

[14]

BOLT (M16X2X60-MM)



12.

7Y-0223

[3]

SHAFT-PLANETARY



13.

094-1542

[6]

BEARING-ROLLER



14.

7Y-1431

[3]

GEAR-PLANETARY (30-TEETH)



15.

094-1528 M

[6]

WASHER (53X84X1-MM THK)



16.

095-0891

[6]

PIN-SPRING



17.

7Y-1428

[3]

GEAR-PLANETARY (32-TEETH)(32 TEETH)



18.

094-0616

[3]

BEARING AS-ROLLER



19.

3E-2338

[2]

PLUG-PIPE



20.

7M-8485

[2]

SEAL-O-RING



21.

7Y-1426

[1]

COVER



22.

7Y-0225

[3]

SHAFT-PLANETARY



23.

094-0611

[6]

WASHER (47.3X76X1-MM THK)



24.

094-0580

[1]

PLATE (10-MM THK)



25.

7Y-1427

[1]

GEAR-SUN (14-TEETH)(11 TEETH)



26.

7Y-1430

[1]

GEAR-SUN (17-TEETH)



27.

7Y-1558

[1]

SPACER (90X119.6X7.5-MM THK)



28.

7Y-1432

[1]

CARRIER



29.

7X-2568 M

[16]

BOLT (M20X2.5X180-MM)



30.

8T-4123

[16]

WASHER (3.62X5.75X0.375-MM THK)



31.

1U-8846 B



SEALANT-GASKET



32.

095-1270 M

[2]

SETSCREW-SOCKET (M12X1.75X30-MM)(M12X1.75 THD)



33.

7Y-1631

[1]

GEAR-RING
