Caterpillar spare parts 129-7859 1297859 for E320C

CATERPILLAR Hydraulic pump bearing 129-7859 1297859

129-7859 BEARING Caterpillar parts fit: E318C, E319C, E320C, E320D, E320D2, E321C, E323D L.



CATERPILLAR excavator Hydraulic pump bearing 129-7859

P/N 129-7859 Material:
GCR15
i/d mm
O/D
mm
H mm
Brand: ZHZB
Precision
P0 , P6 , P5
Structure:
Needle bearing

Product features:
1. Special bearing for excavator Hydraulic pump
2. It can bear the load from both axial and radial at the same time
3. High-strength high-quality steel
4. Smooth rotation and low noise
5. Compared with other companies' Hydraulic pump bearings, the service life is increased by 50%
Our advantage:

100% factory quality inspection;
Minimum order quantity: 1;
Faster delivery efficiency;
Higher cost performance;
Have a mature production line so that we can customize according to the samples or drawings provided by customers;
Professional manufacturer of Hydraulic pump bearings for excavators. Have many years of manufacturing experience

Production Process






Product Photos

129-7859CATERPILLAR 129-7859beaing 129-7859



Any other parts for the travel gearbox system you need , pls search from below picture and form list then mark to me , we will quote to you.

CATERPILLAR parts

Pos.

Part No

Qty

Parts name

Comments

1.

173-3382 Y

[1]

ACTUATOR GP-PUMP (DRIVE PUMP)



2.

177-2470

[1]

COVER



3.

7X-2557 M

[1]

BOLT (M16X2X140-MM)



4.

177-2471

[1]

COVER



5.

8T-4956 M

[6]

BOLT (M12X1.75X35-MM)



6.

173-3383 Y

[1]

ACTUATOR GP-PUMP (DRIVEN PUMP)



7.

8T-4176 M

[2]

BOLT (M12X1.75X90-MM)



8.

8T-4193 M

[6]

BOLT (M16X2X50-MM)



9.

094-1882

[16]

PLUG



10.

191-5600

[1]

BLOCK-PORT



11.

129-7979

[4]

DOWEL



12.

9S-4185

[3]

PLUG (3/4-16-THD)



13.

3K-0360

[3]

SEAL-O-RING



14.

8T-4136 M

[18]

BOLT (M10X1.5X25-MM)



15.

173-3371

[1]

BODY



16.

150-5782

[2]

COVER



17.

8T-4139 M

[4]

BOLT (M12X1.75X30-MM)



18.

129-7863

[1]

COVER



19.

129-7857

[1]

GASKET



20.

179-9763

[1]

FLANGE



21.

189-9763

[8]

SEAL-O-RING



22.

095-0946

[2]

RING-RETAINING



23.

129-7921

[2]

RING-RETAINING



24.

150-5785

[10]

DOWEL



25.

114-0491

[2]

PISTON AS



27.

173-3498

[1]

BARREL AS





173-3499

[1]

PLATE-VALVE



28.

177-8740

[1]

SEAL-O-RING



29.

191-5599

[2]

PLUG



30.

160-4409

[2]

ORIFICE



31.

158-9022

[1]

COVER



32.

8T-3338

[2]

SEAL-O-RING



33.

129-7859

[2]

SET-BEARING



34.

118-4057

[18]

SPRING



35.

7Y-4215

[2]

SPACER



36.

173-3427

[2]

GUIDE-BALL



37.

173-3473

[2]

PLATE



38.

177-2461

[2]

SWASHPLATE AS









  (EACH INCLUDES)



173-3428

[1]

BUSHING



39.

177-2583

[4]

BEARING



40.

129-7927

[2]

BEARING



41.

129-7855

[1]

GASKET



42.

173-3392

[1]

SHAFT



43.

7M-8485

[2]

SEAL-O-RING



44.

8J-4645

[2]

PLUG (STRAIGHT THREAD O-RING)



45.

3J-1907

[1]

SEAL-O-RING



46.

9S-4191

[1]

PLUG (9/16-18-THD)



47.

8T-4196 M

[2]

BOLT (M10X1.5X35-MM)



48.

4I-1022

[2]

ORIFICE



49.

094-1875

[6]

DOWEL



50.

8T-4137 M

[2]

BOLT (M10X1.5X20-MM)



51.

126-2016

[1]

PUMP GP-GEAR (PILOT)



52.

173-3496

[1]

BARREL AS





173-3497

[1]

PLATE-VALVE



53.

8T-4192 M

[10]

BOLT (M12X1.75X25-MM)



54.

129-7854

[1]

CASE



55.

173-3391

[1]

SHAFT-DRIVE



56.

129-7925

[1]

SEAL-LIP TYPE



57.

096-3983

[1]

RING-RETAINING



58.

096-3944

[1]

SEAL-O-RING



61.

8T-4175 M

[2]

BOLT (M16X2X90-MM)



62.

193-1736

[4]

SEAL-O-RING





Company

ZHZB Mission:We are committed to providing bearing component solutions for all construction machinery and equipment!!!

ZHZB was established in 2004 and has been committed to the development and production of engineering machinery bearings. Our products are widely used in mining equipment, road machinery, metallurgy, wind power generation, excavators and other heavy equipment and have been well received by customers!





Packaging



Delivery:

1.We will send express delivery for less than 45 kg, which is more convenient door-to-door.
2.45-200 kg we will choose air transportation, the safest, fastest, and the most expensive
3.For more than 200 kg, we will send it by sea to reduce transportation costs.
