model

SMT-012-045VT

SMT-024-045VT

Output

DC Voltage

12V

24V

Voltage Accuracy

±0.5V

±0.5V

Rated current

3.75A

1.87A

Rated power

45W (class 2)

45W (class 2)

Input

Voltage Range

180～265VAC

Frequency Range

50～60HZ

Power Factor ( Typ.）

PF≧0.94/180V,PF≧0.95/220V, PF≧0.93/265V

Full Load Efficiency（Typ.）

>83%

>83%

AC Current（Typ.）

0.34A/180VAC  0.27A/220VAC  0.24A/265VAC

Leakage current

﹤0.25mA/180V/230VAC

Protection

Short Circuit

Hiccup mode, recovers automatically after fault condition

is removed.

Over voltage

 ≦270VAC(180~265V)

Environment

Working TEMP.

-40～+60℃

Working Humidity

20～90%RH,non-condensing

Storage TEM.,Humidity

-40～+80℃，10～95%RH

TEMP.coefficient

±0.03%/℃（0～50℃）

Vibration

10～500Hz，2G 10min./1 cycle，period for 60min.

each along X,Y,Z  axes

Safety&EMC

Safety standards

EN-60950-1. EN-61347-1/-2/-13

Withstand voltage

I/P-O/P:3.75KVAC

Isolation resistance

I/P-O/P：100MΩ/500VDC/25℃/70%RH

EMC EMISSION

Compliance toEN55015,EN61000-3-2 (≧50%load)

EMC IMMUNITY

Compliance to EN55015; EN61000-4-2,3,4,5,6,8,11,EN61547,Alight industry level （surge4KV）

Others

Weight

0.32Kg

Size

180*60*34mm（L*W*H）

packing

309*279*176mm

Notes

1. All parameters NOT specially mentioned are measured at 120VAC,220VAC input , rated

load and 25℃of ambient temperature.

2. Ripple& noise are measured at 20MHz of bandwidth by using a 12”twisted

 pair-wire terminated with a 0.1uf &47uf parallel capacitor.

3.Tolerance:includes set us tolerance,line regulation and load regulation .
