Cheap Outdoor Garden Gazebo Tent
Cheap Outdoor Garden Gazebo Tent has neoteric shape with 3×3m, 4x4m, 5×5m, 6x6m, 8x8m, 10×10m and 12x12m sizes.As one of the modular and temporary structures, light aluminum frames can be easily transported and installed, high-quality PVC fabrics are waterproof and UV-resistant.
The specification of outdoor gazebo:
|
Type
|
Span (m)
|
Side height (m)
|
Ridge height (m)
|
Peak height (m)
|
Bay Distance (m)
|
Roof Pitch
|
Longest Component (m)
|
Wind Load (km/h)
|
|
MS10/3.3-5HP
|
10
|
3.3
|
4.9
|
7.9
|
5
|
18°
|
5.7
|
100
|
|
MS12/3.3-5HP
|
12
|
3.3
|
5.2
|
8.2
|
5
|
18°
|
6.5
|
100
|
|
MS15/3.3-5HP
|
15
|
3.3
|
5.6
|
8.9
|
5
|
18°
|
5.7
|
100
|
|
Main frame Profile
|
152x120x4mm（4-channel)
|
|
Eave Connection
|
Hot-dip Galvanized Twin Steel Plate
|
|
Roof Fixing
|
Bar Tension
|
|
Frame Material
|
Hard Pressed Extruded Aluminum 6061/T6
|
|
Cover Material
|
Double PVC coated Polyester textile, flame retardant to DIN4102 B1,M2,750-900g/sq.m
|
The accessories of Outdoor Gazebo :
