China Drect Factory Lithium Ion Solar Battery 12V 1000AH

China direct factory lithium ion solar battery

  • PaymentT / T，L / C，Paypal，Western Union，MoneyGram
  • Total energy capacity4.84 kWh
  • CertificateUN38.3, IEC62619, IEC-61000-6-1/3
  • Depth of discharge (DOD)> 95 %
  • Battery typeLi-ion
  • Battery capacity94 Ah
Facebook Twitter Pinterest LinkedIn 分享


1. Modular design of system components, all terminals are designed for easy installation and maintenance.
2. High charge and discharge cycle efficiency, system maximum efficiency up to 97%.
3. With advanced long cycle life, 6,000 cycles still have 80% charge and discharge capacity.
4. BMS uses a 3-level design for real-time data collection
status monitoring and control to protect lithium battery safety.
5. Global safety certification from cell to system: UL1642,UN38.3. UL1973 VDE JET


Technical Data

Technical Data
Total energy capacity 4.8 kWh
Battery capacity 94 Ah
Nominal voltage 51.52 V
Battery type Lithium ion
Voltage range 44.8 V–58.1 V
Max. charge current 47 A
Max. discharge current 80 A
Round-trip efficiency (RTE) > 95 %
Depth of discharge (DOD) > 95 %
Cell balance technique Bi-directional active cell balancing
Cell balance current 5 A
Scalability Yes, up to 14.4 kWh
Over/under voltage protection Yes
Over current protection Yes
Over/under temperature protection Yes
Short-circuit protection Yes
Mounting type Free-standing / wall-mountable
Weight 48 kg
Dimensions (W x H x D) 510 mm x 565 mm x 190 mm
Communication CAN
Firmware upgrade Local and remote
Current consumption in sleep mode < 30 µA
Noise < 30 dB
Ingress protection rating IP55
Relative humidity range 0–85 %, non-condensing
Operating temperature -10°C to 45°C
Storage temperature -20°C to 50°C
Altitude < 2000 m
Storage period Less than 6 months
Cooling strategy Natural convection
Certification UN38.3, IEC62619, IEC-61000-6-1/3, SAA
