Traction type
|
6X4
|
Driving type
|
Left hand driving or Right hand driving
|
Dimension(Lx W xH)(unloaded)
|
10576x2500x3130
|
Approaching angle/Departure angle(°)
|
26/20
|
Overhang(front/rear) (mm)
|
1410/2666
|
Wheel base (mm)
|
5050+1450
|
Max speed (km/h)
|
90
|
Curb weight (kg)
|
12000
|
Loading Weight (kg)
|
25,000
|
Engine
Steyr technology, made in China
|
Model:WD615.340
|
water-cooled,four strokes,6 cylinders in line,turbocharged, directly injection With the exhaust valve brake
|
Displacement (L)
|
9.726/Diesel
|
Bore X stroke (mm)
|
126/130
|
Max power (kw/rpm)
|
247/2200 (340hp)
|
Max torque (Nm/rpm)
|
1350/1300-1600
|
Emission
|
EURO II
|
Fuel tanker(L)
|
400L steel fuel tanker
|
Clutch
|
Model
|
430 Diaphragm type
|
Gearbox
|
Model
|
9JS150 (Fuller)
mechanism,9gears,1reverse gear, manual,
|
Brake system
|
Service brake
|
Brake gap can be adjusted automatically, double circulation air brake system
|
Assistant brake
|
Engine exhaust brake
|
Park brake
|
Potential springs pressing on middle and rear wheels
|
Steering system
|
Model
|
ZF8098
|
Frame
|
Fish belly, shape, variable width, variable sections, side beam structure
|
Front axle
|
7.5T: Double-shoe pneumatic brake, non-driving steering axle
|
Middle and Rear axle
|
13T: Double-shoe pneumatic brake, casting, double reduction driving axles with inter-wheel & inter-axles differential locks
|
Transfer case
|
VG1400
|
Tyre
|
12.00R20 Radial tyre Number of tyre:10+1 spare
|
Electrical system
|
Battery
|
2X12V/135Ah
|
Generator
|
28V-35A
|
Starter
|
5.4Kw/24V
|
Cab
|
Using Mercedes-Benz technology NG80B long Cabin, single sleeper with air-conditioner
Full steel skeleton structure, covered with double layer steel plate;
Can be tipped forwardly;
|
Water tank
|
Steel quality
|
Carbon steel
|
Compartment
|
Single
|
Loading valve
|
1
|
Discharge valve
|
1
|
Tube
|
10meters
|
Tank capacity (Liter)
|
20,000
|
Thickness of the tanker body
|
the thickness of the shell is 4mm approx;
|
Dish ends
|
the thickness of the shell is 5mm approx;
|
