ASR1006-X Overview
The Cisco ASR 1006 Router in a 6-rack unit (RU) form factor is the most flexible edge routing solution in the Cisco ASR 1000 Series. It has the option of dual route processor and embedded services processor support with 10 Gbps throughput support. It also supports up to 12 shared port adapters (SPAs), which makes it the highest port density solution of the three Cisco ASR 1000 Routers.
ASR1006-X Specification
Technical Specifications
General
Device TypeModular expansion baseEnclosure TypeDesktop, rack-mountable - modular - 6UConnectivity TechnologyWiredFeaturesFront to back airflowCompliant StandardsCISPR 24, EN55022, EN55024, CISPR 22, EN50082-1, EN 61000-6-1, AS/NZS 60950-1, EMC, ICES-003 Class A, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1-03, AS/NZS, VCCI Class A, FCC CFR47 Part 15 B Class ARAM8 GB
Expansion / Connectivity
Expansion Slots16 (total) / 16 (free) x expansion slotInstalled Modules Qty (Max)0 (installed) / 16 (max)
Power
Power DeviceExternal power adapter - hot-plugPower RedundancyOptionalInstalled Qty6 (max)Voltage RequiredAC 120/230 V / DC -40 -72 V
Dimensions & Weight
Width17.2 inDepth18.1 inHeight10.5 inWeight36.6 lbs
Manufacturer Warranty
Service & SupportLimited warranty - advance hardware replacement - 90 days - response time: 10 days
Environmental Parameters
Min Operating Temperature32 °FMax Operating Temperature104 °FHumidity Range Operating5 - 90
