The product description
Longhua die casting machine is suitable for industrial road railway aviation agricultural machinery. Mechanical parts are processed by CNC center self to form a precision die locking system.In order to guarantee theinjection concentricity and stability, the complete cast steel structure C frame is adopted uniquely.
Product parameters
LH series of standard parameter table (350 t)
|
ITEMS
|
Unit
|
Specification
|
|
HYDRAULIC WORKING PRESSURE
|
MPa
|
14
|
|
CLAMPING FORCE
|
KN
|
3500
|
|
SPACE BETWEEN TIE BARS
|
mm
|
600*600
|
|
Tie Bar Diameter
|
mm
|
￠120
|
|
DIE OPENING STROKE
|
mm
|
500
|
|
INJECTION FORCE(intensify)
|
KN
|
360
|
Plunger launch distance
|
mm
|
180
|
|
Injection position
|
mm
|
0 -- 160
|
|
PLUNGER DIAMETER
|
mm
|
￠50----￠80
|
|
INJECTION STROKE
|
mm
|
480
|
Casting pressure (intensify)
|
MPa
|
184/127/94
|
Casting Fiange Protrusion
|
mm
|
12
|
Casting Fiange Diameter
|
mm
|
110
|
|
MAX CASTING AREA UNDER 40Mpa
|
CM2
|
875
|
|
lnjection Weight(Al)
|
Kg
|
3.8
|
|
Die Height(Min--Max)
|
mm
|
250～750
|
|
EJECTOR FORCE
|
KN
|
180
|
|
EJECTOR STROKE
|
mm
|
110
|
|
Motor Capacity
|
Kw
|
18.5
|
|
Machine Dimensions (L*W*H)
|
m
|
6.8*1.8*2.7
|
|
Referential Machine Weight For Uplifting
|
T
|
14.2
|
|
Oil Tank Capacity
|
L
|
700
|
WE reserve the right to make any technical improvement without further notice
Die casting machine related products
Exemption certificate for import and export inspection
