Compack Battery Vacuum Sealer Machine for Preparing Pouch Cell
Product specification
TOB-YF350-S compact vacuum sealer is mainly used for sealing aluminum-laminated case in glove box after injection of electrolyte into pouch Li-ion cell or after formation for final seal (polymer Li-Ion cell). Heatable sealer blade is built into the chamber, automatically sealing the aluminum film pouch case for polymer battery.
|
Model
|
Compact Vacuum Sealer TOB-YF350-S
|
|
Source voltage
|
AC 220V, 50HZ
|
|
Power
|
2000W
|
|
Warranty
|
One year limited warranty with lifetime support
|
|
Vacuum degree
|
More than -95Kpa
|
|
Sealing head TEM
|
RT-250℃, adjustable
|
|
TEM accuracy
|
±2℃
|
|
Sealing time
|
1-99s, adjustable
|
|
Sealing Blade
|
Hard type (without rubber, only for Al case sealing,
not suitable for sealing case with tab in between)
|
|
Sealing width
|
8mm (Customized)
|
|
Sealing head length
|
350mm
|
|
Suitable battery size
(Inner size)
|
350*200*15mm
|
|
Air source
|
0.5-0.7MPa
|
|
Package Size
|
120*60*55cm
|
|
Package weight
|
90kg
|
Product Images
Product Packing
