Composite Rubber Hose

Composite hose by a variety of materials multi-layer sealing structure, in the worst environment still has better rupture and leakage resistance, will not burst suddenly, can easily handle gasoline, diesel, crude oil and a variety of chemical liquid transmission work, even in cold weather still can maintain high flexibility. Light weight, strong toughness, easy to handle, soft tube body, flexible use, high temperature resistance, low temperature, anti-aging, no deformation, corrosion resistance, exposed inner spiral metal and special inner layer, with reliable electrostatic escape performance.

Construction:

Lining: Polypropylene

Inner/Outer Wire: Galvanized Steel/Stainless Steel Wire

Cover: PVC coated nylon, abrasion, UV and ozone resistant

Work Temperature Range: -30℃~+110℃

Work pressure: ＜=30Bar

Min. Burst Pressure: 80 BAR

40 Bar hydrostatic test, no leakage and obvious deformation

Applied: Suction and discharge of petroleum, standard HFO 180cst/380cs.

Conveying medium: conveying fuel liquid gas, gasoline, diesel, kerosene, crude oil and other hydrocarbon products

Features:

1. Light weight

Composite hose is about 40% lighter than rubber hose of the same caliber and length.

2. Good flexibility and free bending

The radius of curvature is 1/3 times that of the rubber hose and the metal hose. The composite hose can still work normally under a very small radius of rotation. In its bending part, the tube always maintains a round shape and does not fold, fall off the inner wall, block and crack the tube body.

3. Good resistance to positive and negative pressure

4. Good temperature resistance

The maximum operating temperature can reach 200℃

5. It has good acid and alkaline resistance

6. With good flame retardant material manufacturing, excellent flame retardant performance.

7. Reliable electrostatic export function

8. Strong and durable
