Truck Description:
CNCSC Concrete Mixer Tank is adopted pear shaped structure has small inclination angle and low center of gravity, so driving is safe and stable. The tank and blades are made of special wear resistant steel, which can enhance wear resistance and prolong service life.
Advantages:
1. DAYUN chassis, quality assurance.
2. Optional from 4CBM to 18CBM
3. Engine emission standard can choose EuroⅡ,EuroⅢ,EuroⅣ,EuroⅤ.
4. Mixing drum and blade using high strength steel T510
|
Concrete Mixer Truck DAYUN 8m³
|
|
Truck
description
|
GVW (kg)
|
25000
|
|
Kerb weight (kg)
|
15460
|
|
Overall
dimension (mm)
|
Length
|
10150
|
|
Width
|
2550
|
|
Height
|
3975
|
|
Chassis
|
Number of axles
|
3
|
|
Allowable Passengers in cab
|
2
|
|
Air conditioner
|
For option
|
|
Wheel base(mm)
|
4100+1350
|
|
Type of fuel
|
Diesel
|
|
Exhaust/output
|
9726ml/247kw
|
|
Tire specification
|
for option
|
|
Tank
description
|
Material
|
T510 alloy steel
|
|
Thickness
|
tank (mm)
|
6
|
|
head(mm)
|
8
|
|
Blade（mm）
|
5
|
|
Equipment
|
China pump and motor, reducer.
|
|
Mixer volume
|
8m³
|
|
Other remark
|
Above specification is just for reference, please send us your request details.
|
|
