| Model No.
|
CSN-400
|
| Printer Method
|
Thermal line printing
|
| Paper Dimensions
|
Paper width:30-110mm
Paper thickness:80-180μm
Paper roll outer dia.:Max.110mm
Paper roll core dia.:25mm
|
| Paper Loading Structure
|
Spindle
|
| Printing Width
|
Max. 108mm
|
| Print Density
|
203dpi(8dots/mm)
|
| Print Speed
|
Max. 150mm/s
|
| TPH Life/MCBF
|
100km
|
| Character Set
|
Font A:12*24, Font B:9*17, GBK:24
|
| Character Size
|
ASCII:9*17, 9*24, 16*18, 12*24
|
| Character Per Line
|
Font A(12*24):48
Font B(9*17):64
GBK:24
|
| Barcode
|
CODE128, EAN128, ITF, CODE39, CODE93, EAN13, EAN13+2, EAN13+5, EAN8, EAN8+2, EAN8+5, CODABAR, POSTNET, UPC-A, UPCA+2, UPCA+5, UPC-E, UPCE+2, UPCE+5, CPOST, MSI, MSIC, PLESSEY, ITF14, EAN14, QR CODE
|
| Auto-Cutter
|
Tear off or Peel off
|
| Interface(Standard)
|
USB
|
| Power Supply
|
DC24V, 2A
|
| Printing Command
|
Compatible with ESC/POS, TSPL, CPCL set
|
| Overall Dimensions
|
180W*230D*180H mm
|
| Weight
|
1.0KG
|
| Temperature
|
Operating:5℃-40℃
Storage:-20℃-50℃
|
| Humidity
|
Operating:10%RH-80%RH
Storage:10%-90%RH
|
Applications:
1. Communication
2. Post
3. Retail
4. Logistics
Company Information:
Xiamen Cashino Technology Co., Ltd. is a professional manufacturer of thermal printers since 2011, with the ISO9001, CE, Rohs and FCC certificates passed. We have a wealth of in dependent research and experience, which can effectively meet different customers ODM requirements and help achieve printing simply, efficiently and economically. Currently, Our products are exported to Southeast Asia, South Asia, South & North America, Middle East and Europe, etc.
Our Services:
FAQ:
Q: About samples
A: Samples are available for testing.
Q: Delivery date.
A: All the printers for samples are in stock, can ship it within 2 days after payment received. For bulk order
delivery date approximately 2 weeks.
Q: Payment terms
A: Paypal, western union, T/T in advance, or order in aliexpress.
Q: Warranty
A: One year warranty. During warranty period, the damage caused by non-human factor, CASHINO will be
responsible for the free repair. Overdue warranty period, CASHINO will continue to provide services with
reasonable price to the customer.
