Cummins Silent Generator Diesel 100kva 6BT5.9-G2
Around 1 million Cummins engines are in operation around the world in applications from combine harvesters, tractors and sprayers to specialist and autonomous equipment.
Ranging from 2.8 to 19 litres, Cummins agriculture engines are tailored for farm performance, with the power bulge and torque back up available for tractor operation (frame and structural) or the high power density that today’s combine harvesters and sprayers require.
Output Ratings
Phase Rating, 50Hz, PF 0,8
|
Voltage
|
Standby Rating (ESP)
|
Prime Rating (PRP)
|
|
kVA
|
kW
|
kVA
|
kW
|
|
400/230
|
110
|
88
|
100
|
80
|
Diesel Engine Specifications
Diesel Engine Technical Parameters
|
|
Brand/origin:
|
Cummins
|
|
Cooling mode:
|
closed cooling water circulation
|
|
Model:
|
6BT5.9-G2
|
|
Rated power:
|
80KW
|
|
Standby power:
|
101KW
|
|
Cylinder
|
4
|
|
Engine oil capacity:
|
8L
|
|
Rated speed:
|
1500rpm
|
|
Startup mode:
|
DC 24V electric start
|
|
|
Alternator Specifications
|
Alternator brand
|
TAL-A44-D
|
|
Prime power
|
100kva
|
|
Frequency/speed
|
50HZ
|
|
Exciter type
|
Brushless
|
|
Power factor
|
0.8
|
|
Voltage adjust range
|
≥5%
|
|
Voltage regulation NL-FL
|
±0.5%
|
|
Insulation Grade
|
H
|
|
Protection Grade
|
IP23
|
100kva diesel generator (Control panel)
|
Brand
|
Deepsea/ComAp
|
|
The control module gives digital readouts of:
Generator voltage;
Output frequency;
Engine speed;
Battery voltage;
Engine hours run.
The control module has indicators for failure
information:
Overspeed/underspeed,
Emergency stop
Low oil pressure;
High water temperature
Failure to start
Battery charger failure
Automatic shutdown occurs under:
Low engine oil pressure;
High engine water temperature;
Overspeed/underspeed;
Failure to start after three attempts.
|
Perkins Standby Generator 80KW/100KVA 4016TAG2A Photos
-
24 hours continuous stable power supply, in extreme or normal temperatures from -10 °C to 50 °C.
AI Power generators are design to work 24*7 in extreme temperature conditions with minimum maintenance requirement.
-
In some cases CHP & CCHP (Combined heat and power/ Combined cooling heat and Power) to utilized heat.
AI Power specially designs Diesel and Gas CHP/CCHP Power generators to provide hot water or steam as well as Power.
-
Lower noise level is important.
AI power generators are made to be environment friendly with low emission and lower noise level
-
Reliable AMF & ATS System (Auto mains failure & Auto transfer System) which can start and stop generators automatically with load transfer in case of city supply on or off.
1.Q: What is your MOQ of this item?
A:1 Set
2.Q: What is the lead time?
A:7 working days after received the 30%T/T deposit
3.Q: Is it all right to make customer's own brand name?
A:We can be your OEM manufacture with your authorization of brand.
4.Q: Where is your Loading Port?
A:Shanghai or others
5.Q: What are your payment terms?
A:30% TT as deposit,70% TT before Shipment.
6.Q: What is your company's available production capacity?
A:100 Sets per month
7.Q:What's the warranty time of diesel generators?
A:12 Months or 1000 working hours
