Dc 24v power supply, safety for lifting.
Durable steel construction, enamelled wire, high temperature resistant, with two depth 10mm M5 mounting teeth at the bottom, easy to install and operation.
Product Description
|
Brand
|
Landa
|
Model
|
H503016
|
|
Place of Origin
|
Guangdong, China
|
Certification
|
CE,ROHS,ISO9001
|
|
Dimension(L*W*H)
|
50*30*16 mm
|
Rated Voltage (V)
|
DC 12/24
|
|
Rated Power(W)
|
3.5-7
|
Work Model
|
Holding Type
|
|
Holding Force (N)
|
100-120
|
Stroke(mm)
|
0
|
|
Reset Time(s)
|
0.2
|
Service Life
|
500 Thousand Times
|
|
Material
|
Iron
|
Lead Wire Length(mm)
|
200
|
|
Install Style
|
Screw
|
Tolerance of Dimension
|
gb/t1804-m
|
|
Water-proof
|
IP65
|
Insulation Class
|
B
|
|
Residual Magnefism
|
/
|
Duty Cycle
|
50%-100%
|
|
Working Temperature
|
-10°C-100°C
|
Thread Size(mm)
|
M5
|
|
Thread Depth(mm)
|
10
|
Payment Term
|
TT,PAYPAL
|
|
Sample Order
|
Yes
|
Warranty
|
1 year
|
|
MOQ
|
2 pcs
|
Supply Ability
|
5000 pcs per Week
|
|
Delivery Time
|
3 Days
|
Port of Loading
|
Zhongshan
|
|
Weight
|
Packaging Details
|
Shipment Details
|
|
N.W.(KG)
|
G.W.(KG)
|
Product Size(mm)
|
Carton Box Size(mm)
|
20GP
|
40GP
|
40HQ
|
|
0.032
|
0.032
|
50*30*16
|
350*310*180
|
/
|
/
|
/
|
Product Features
Small size, with force power on and without force power off Smooth and flat surface, saving energy,
safe and reliable.
Durable and easy to operation. Durable steel construction, copper wound coils, high temperature resistant, with two depth 10mm M5 mounting teeth at the bottom, easy to install and operation.
Materials
High quality iron house & core. High temperature resistance lead wire and copper wire. Efficient conductivity, outlet can be customized
Epoxy filled, IP65 waterproof class.
OEM/ODM is welcome
11 years of designing and producing experience,CE, ROHS, ISO9001, UL certification
Good quality, best service, competitive price
