DC traction electromagnet

MQZ1 DC traction electromagnet is mainly used in the control circuit of DC 220V, as the electromagnet coil for switching of motorized operating device of vacuum circuit breaker and switchgear incoming/outgoing cables.




Characteristics MQZ1 DC traction electromagnet



* Easy to fix and connect to the load

* The risen temperature is stable so as to prolong lifetime and guarantee excellent performance

* Anti-friction ensures high efficiency and long lifetime

* Full resin encapsulation in high IP protection level


Coil Voltage

220VDC /110VDC

Rated Attraction

7N

Rated Travel

12mm

Operation Frequency
(Power duration <1s)

180(times/H)

Limit of temperature rise

65(K)

Lifetime

>10000 times

Dielectric Property

AC2000V,1min

Environment

Altitude

1000m

Temperature

-25 +40

Humidity

95%

Pollution Degree

2
