DCS-25 semi auto weighing bag stitch sewing grain packaging machine
Introduction:
DCS-25 semi auto weighing bag stitch sewing grain packaging machine includes one set of DCS-25 automatic weighing machine, one set 2.5 meters belt conveyor, one set of sewing machine, used for weighing filling granules, such as: rice, seeds, grains, etc. in pp woven bags and sewing the bag.
Technical features:
No. | Features |
1 | Convenient to be operated: only need to coat bag manually and touch bag-clip switch charging, feeding, inflation and discharging will be completed automatically; |
2 | Matching high accuracy sensor, one gate main feeder and one fine feeder cooperating work in order to keep high accuracy; |
3 | Software self-adapting, error automatically amended more-less alarming ,trouble self-inspected functions, etc.; |
4 | Number and quantity of package automatic counting, printing and data communication functions, etc.; |
5 | Widely range of quantitative, high precision and matching with a bag-sewing machine which has multi-functions and high effective; |
6 | Adopting imported pneumatic organ which is reliable, easy to maintenance and non-polluted; |
7 | The machine part contact with material adopting stainless steel 304 which is safe and sanitary and not easy to eroded. So the equipment has a long life; |
8 | We will adopts the ware resistance plastic bear which no need bath the oil. |
Application:
| Granule: grain, granular drug, capsule, seed,fertilizer, condiments, granulated sugar, chicken essence, melon seeds, nuts etc. |
Technical Form:
No. | Item | Parameter |
1 | Metering way | Weighing type ,auger screw filling |
2 | Packing weight | 5-25kg |
3 | Packing accuracy | ±0.2% |
4 | Packing speed | 8-10bags/min（depending on actual material) |
5 | Voltage | Voltage:3 phase 220V 50Hz |
6 | Power supplier | 1.5KW |
6 | Weight | 380kg |
7 | Hopper volume | 125L |
8 | Material | Parts contact with material are made of SUS304 stainless steel |
