Deep 75mm carbon rims 700C tubeless road bicycle wheels

Type:75mm Deep tubeless clincher rim

Appearance:3K/UD/12K or customized

250°C high TG braking temperature

700C new design Carbon Clincher tubeless Rims

U shape 25mm wide design

High quality bicycle rims manufacturer



Product Model:75mm Deep wheels 700C Clincher carbon rims

Tish 75mm Deep clincher carbon rims with 250°C high TG resin system,can tolerate max 250°C high temperature from braking,solve heating problem on the rim brake clincher bike wheels.

25mm wider U shape,Tubeless ready design.Basalt braking surface for road bike.Lightweight road bike clincher rims offers improved aerodynamics.better for racing,climbing and riding.

700C Carbon rims with UD Appearance, to be more resistant to high temperature.so has low braking failure rate and stable brake surface.

25mm wide carbon wheels made of Toray T700 and T800 carbon fiber.better for the stiffness and strength.Different patterns of brake surface optional. comfort for track road bike wheels.

High quality tubeless carbon clincher rims with the wholesale price,fast delivery.

75mm Deep carbon rim

clincher tubeless rim
road bicycle carbon rim


Features:

1.Newest style 75mm Deep clincher carbon rims,Tubeless Ready design,easy for tire mount.

2.U shape wider design,makes road tubeless rims lightweight,better strength and stiffness.keeping them stable in crosswinds condition.

3.250°C high TG resin system,can tolerate max 250°C high temperature from braking.

4.UD appearance to be more resistant to high temperature.

5.Manufacturer of high quality road and MTB Bike carbon wheels.

6.We offer decal and painting service for OEM your brands.

7.We can customized Different patterns of brake surface .

8.5 years warranty


Specification:

Model

R75C-25

TR75C-23

TR75C-25

Size

700C

700C

700C

Sectional Drawing

75mm deep clincher rim

tubeless carbon rim

700C carbon rim

Material

Toray T700 & T800

Toray T700 & T800

Toray T700 & T800

Depth

75mm

75mm

75mm

Wide

25mm

23mm

25mm

Weight

515+/-15g

520+/-15g

525+/-15g

Appearance

3K/UD OrCustomized

3K/UD OrCustomized

3K/UD OrCustomized

Spokes holes

18-36#Customized

18-36#Customized

18-36#Customized

ERD

700mm

700mm

700mm

Assembly Hole Dia.

7.6mm

7.6mm

7.6mm

Spokes hole Dia

4.2mm

4.2mm

4.2mm

Valve hole Dia.

6.6mm

6.6mm

6.6mm

Flatness

<0.25mm

<0.25mm

<0.25mm

Roundness

<0.5mm

<0.5mm

<0.5mm

Max Spoke Tension

>300kg

>300kg

>300kg

Ultimate Strength

>300kg

>300kg

>300kg

Torsion Strength

>50kg

>50kg

>50kg

Tire Size Recommended

700*25-28c

700*21-25c

700*25-28c

Max Tire Pressure

125psi/8.6bar

125psi/8.6bar

125psi/8.6bar


Factory production manufacture

customication carbon wheel


100% Quality Inspection:

Our rims are made of 100% Full carbon fiber material to ensure the high quality of the goods. Each carbon rim by us has its unique serial ID number, which follow every step of the product. And confirm every rim to ensure the best after-sale service.

5 years warranty:

The warranty covers five years form the initial pruchase of the product.

The warranty applies to the original purchaser and the assignmnet is invalid.

The warranty requires proof of pruchase,product serial number and defect picture.

Please keep your proof of purchase for any future warranty problems.

This warranty does not cover:

1. Normal wear and tear and depreciation.

2. Any man-made damage caused by accident,misuse,etc.

3. Improper installation,maintenance or other conduct by an unauthorized technician.
