Specification

LIGHT SOURCR

Light source: 252 pcs Tianxin LED bead (R: 84 G: 84 B: 84)

Lifepsan: 50,000H

COLOR

 R, G, B linear color change, linear transformation and colorful rainbow effect

MOVEMENT

Moving mode: ball goes up and down at variable speeds

Speed of lifting: 0.3 meter/second(maximum)

FEATURES

Colors: RGB can be separately dimming, 16 bit precision fine-tuning, RGB mixing makes 16.7 million colors
Dimming: electronic dimming 0-100% linearly adjustable,

Strobe: electronic 1-20Hz or random.

SOFTWARE

Control mode: DMX 512, master-slaves,Auto, Madrix software

DMX Channel: 10CH

OTHER SPEC

1.Widely used in the venue to do special effects with three-dimensional pattern

2. Semi-transparent special plastic material for housing of ball, not easy to fracture, uv protection.

3. The ball has high brightness LED bead (R.G.B), wide angle transmission, 360 ° visible

4. Madrix or controller for programming

5. Lifts and ball independently packed, convenient installation.

POWER

AC100V-240V, 50-60Hz

Power consumption: 150W@220V

DIMENSIONS AND WEIGHT
Fixture dimension: motor 29*15*36cm

                           ball dia 35cm

Packing dimension:

                           motor 50x45x30cm(Carton)

                           ball 36x36x36cm  (Carton)

Net Weight:

                            motor 8kg

                            ball 1.5kg

Gross Weight:

                           motor 10kg(Carton)

                           ball 3kg (Carton)
