Dimensions :
|
Tare weight
|
15000kg
|
Payload
|
60000kg
|
|
Overall Length
|
11000mm
|
Overall Width
|
2500mm
|
Overall height
|
3500mm
|
Specification :
|
SPECIFICATION
|
|
Chassis
|
Heavy duty and extra durability designed
i beam；opting for high tensile steel Q345，welded by automatic subrnerged-Arc processes. Top
flange 16mm，width 200mm；Middle Flange 8mm；bottom
flange16mm，width 200mm
|
|
Axle
|
Number
|
3
|
Brand
|
Optional upon choice
|
Capacity
|
13T
|
|
Suspension
|
Mechanical suspension Or air suspension
|
|
Leaf spring
|
Leaf spring or air bag
|
|
Floor
|
3mm bottom plate.side wall 2mm
|
|
Tire
|
11.00R20，12.00R20，11R22.5，12R22.5，315/80R22.5 Tire optional
|
|
Wheel rim
|
8.5-20，9.0-20,8.25-22.5,9.0-22.5
steel wheel rim optional upon choice
|
|
Kingpin
|
2”/3.5”bolt-in king pin
|
|
Landing gear
|
JOST brand two-speed，manual operation，heavy duty
landing gear
|
|
Vehicular applications
|
Cargos transport
|
|
Braking system
|
WABCO RE6 relay valve；T30/30 sping brake chamber；40L air tanks
|
|
Painting
|
Complete chassis sand blasting to clean
rust，1coat of anticorrosive prime，2coats of final paint
|
|
Accessories
|
one standard tool box
|
