EHWIC-VA-DSL-B Overview
The Cisco Multimode VDSL2 and ADSL2/2+ EHWIC (EHWIC-VA-DSL) provides 1-port multimode VDSL2 and ADSL2/2+ WAN connectivity . In combination with the Cisco 1921 and 1941 Integrated Services Routers (ISRs) and Cisco 2900, 3900, and 3900E Series ISRs, this EHWIC provides high-speed digital data transmission between customer premises equipment (CPE) and the central office (DSL access multiplexer [DSLAM]), usually located on the telephone company premises. This capability enables service providers and resellers to offer additional services such as business-class security; voice, video, and data; differentiated classes of service (QoSs); and managed network access with Cisco IOS? Software over existing telephony infrastructure. These value-added features, along with the flexible manageability and reliability of Cisco IOS Software, provide the mission-critical networking features that businesses expect.
With Cisco IOS 15.1(3)T/15.1(4)M and later releases, the 1-port multimode VDSL2 and ADSL2/2+ EHWIC is supported on the following Cisco ISR G2 routers: Cisco 1861E, 1921,1941, 2901, 2911, 2921, 2951, 3925, 3945, 3925E, and 3945E ISRs. The Cisco 1861E ISR is supported starting with Cisco IOS Software Release 15.1(4)M.
EHWIC-VA-DSL-B Specification
|
Brand
|
Cisco
|
|
Part
number
|
EHWIC-VA-DSL-B
|
|
Product
Description
|
Multi Mode VDSL2/ADSL/2/2+ EHWIC
Annex B
|
|
Product
Type
|
Interface
Module
|
|
Application/Usage
|
Data
Networking
|
|
Interfaces/Ports
|
1 x VDSL2
WAN
|
|
Interfaces/Ports Details
|
1 x RJ-11
VDSL2 Network WAN
|
|
Data
Transfer Rate
|
200 Mbps
VDSL2
|
|
Management
|
VLAN
|
|
QoS
|
|
Warranty
|
One year
|
|
Lead
time
|
2-3 business days
|
|
Shipment
|
DHL, Fedex, Aramex, EMS or per
request
|
