Truck description:
Forklift ( also name as hydraulic forklift,forklift truck,fork truck, lift truck,forklift equipment, Electric powered reach truck) is a kind of wheeled transport vehicle which carries out loading and unloading, stacking and short-distance transportation of finished pallets.
Forklifts can be divided into three categories: internal combustion forklift, electric forklift and storage forklift.
Advantage:
1. The whole vehicle adopts advanced ergonomics design principle, the engine is equipped with suspension shock absorber, flexible link of steering bridge, low input torque steering gear, in situ steering easier.
2. The steering wheel can be adjusted according to the working environment and not tired during long working hours. The wide leg space makes the driver comfortable to operate.
3. Suspension design high strength monolithic hood with built-in sound absorption and heat insulation material.
Technical Specification:
We are able to custom manufacture Forklift in a wide range of sizes and capacities as per customers' requirement.
|
Hydraulic Forklift 3T
|
|
Rated loader(kg)
|
3000
|
|
Motive power
|
diesel oil
|
|
Load center distance(mm)
|
500
|
|
Free lift height (mm)
|
188
|
|
Tilting angle of gantry(°)
|
6/12
|
|
The dimension of whole machine
(length x width x height)(mm)
|
3775x1238x2177
|
|
Fork Size (length x width x height)(mm)
|
1070×125×45
|
|
Fork overhang
|
483/522
|
|
Min.turning radius(R)mm
|
2460
|
|
Max.driving speed(km/h)
|
20
|
|
Lifting speed at full load(mm/s)
|
400
|
|
Gradeability(%)
|
20
|
|
Wheel track(mm)
|
1000/970
|
|
Wheelbase(mm)
|
1700
|
|
Min.ground clearance(mm)
|
132
|
