| Identification |
1.1 |
Manufacture's type designation |
HOPPER |
| 1.2 |
Model |
|
|
CQD15B |
| 1.3 |
Power Type |
|
Electric |
| 1.4 |
Type of operation |
|
Stand-on |
| 1.5 |
Steering Mode |
|
Electric Power Steering |
| 1.6 |
Load capacity/rated load |
Q |
kg |
1500 5 |
| 1.7 |
Load center distance |
c |
mm |
500 |
| 1.8 |
Loaddistance. center of drive axle to fork |
X |
mm |
160 |
| 1.9 |
Wheelbase |
y |
mm |
1375 |
| Weight |
2.1 |
Total Weight(with battery_ |
|
kg |
2700 |
| 2.2 |
Axle Load(laden):Drive side/Load-bearing side |
|
kg |
|
| 2.3 |
Axle Load(unladen):Drive side/Load- bearing side |
|
kg |
/ |
| Dimension |
3.1 |
Overlength(Mast fronted/back) |
L1/L2 |
mm |
2820/2355 |
| 3.2 |
Frame Length(without fork) |
L |
mm |
1760 |
| 3.3 |
Overall width |
W1 |
mm |
1270 |
| 3.4 |
Overheadloadguardheight |
h7 |
mm |
2260 |
| 3.5 |
Lif Height |
h1 |
mm |
3000 |
| 3.6 |
Lowered mast height |
h2 |
mm |
2100 |
| 3.7 |
Extended mast height |
h4 |
mm |
3900 |
| 3.8 |
Free lit height |
h5 |
mm |
L |
| 3.9 |
Fork Dimension |
I/e/s |
mm |
1070X100X35 |
| 3.1 |
Type of fork carriage A, B |
|
|
2A |
| 3.11 |
Fork carriage spread width |
b2 |
mm |
225-820 |
| 3.12 |
Fork carriage width |
|
mm |
868 |
| 3.13 |
Forkariagetiltforward/backward |
a/B |
|
44625 |
| 3.14 |
Distance between supporting arm and load side |
b3 |
mm |
920 |
| 3.15 |
Reach Distance |
L3 |
mm |
465 |
| 3.16 |
Height of supporting arm_ |
h6 |
mm |
310 |
| 3.17 |
Ground Clearance at the center of wheelbase (Min) |
m1 |
mm |
80 |
| 3.18 |
Turning Radius |
Wa |
mm |
1675 |
| 3.19 |
Aisle width for lengthwaysPalle size 1001200 |
Ast |
mm |
2860 |
| 3.2 |
Aisle width for lengthways(Pallet size 800*1200) |
Ast |
mm |
2810 |
| Tyre |
4.1 |
Tyre Type |
|
|
Polyurethane |
| 4.2 |
Tyre Size(Front) |
|
mm |
267X114 |
| 4.3 |
Tyre Size(Auxiliary wheel) |
|
mm |
180X55 |
| 4.4 |
Tyre Szedriving Whee) |
|
mm |
$343X135 |
| 4.5 |
Wheels Quantity, front/rear (x=diving wheels) |
|
|
2/1x+2 |
| Performance |
5.1 |
Traveling Speed(aden/unladen) |
|
Km/h |
10月12日 |
| 5.2 |
Llfting Speed(laden/unladen) |
|
mm/s |
270/375 |
| 5.3 |
Lowering Speed(aden/unladen) |
|
mm/s |
300/270 |
| 5.4 |
Max.Gradient Performance S2 5min (laden/unladen) |
|
% |
10月15日 |
| 5.5 |
Service BrakeType |
|
|
Electromagnetic |
| 5.6 |
Parking Brake Type |
|
|
Electromagnetic |
| Power Unit |
6.1 |
Drive Motor Rating(AC) S2-60min |
|
kW |
6.5 |
| 6.2 |
Lift Motor Rating(AC)S3-15% |
|
kw |
12 |
| 6.3 |
battery voltage/Capacity K5 |
|
V/Ah |
48/350 |
| 6.4 |
Battery Weight |
|
kg |
650 |
| Others |
7.1 |
Controller Brand |
|
|
CURTIS |
| 7.2 |
Controller Model |
|
|
2-1 234SE12222 |
| 7.3 |
Sound level driver's ear according to EN 12053 |
|
dB |
70 |
| CQD15B Mast parameters |
|
|
|
|
|
| Designation |
Lift height |
Lowered mast height |
Extended mast height |
Free fitt height |
Load capacity |
| mm |
mm |
mm |
mm |
kg |
| One-stage |
1600 |
2100 |
2500 |
1600 |
1500 |
| Two sage |
2500 |
1850 |
3400 |
/ |
1500 |
| 3000 |
2100 |
3900 |
/ |
1500 |
| 3500 |
2350 |
4400 |
/ |
1500 |
| 4000 |
2600 |
4900 |
/ |
1500 |
| Thee-sage ful feemast |
3500 |
1820 |
4400 |
1170 |
1500 |
| 4000 |
1985 |
4900 |
1350 |
1 500 |
| 4500 |
2150 |
5400 |
1530 |
1200 |
| 5000 |
2300 |
5900 |
1710 |
1000 |
| 5500 |
2470 |
6400 |
1860 |
800 |
| 6000 |
2640 |
6900 |
2030 |
600 |
