1. Advantage:
●New advanced car outline, completely opened cover, distinguished and beautiful.
●Full AC electric system has brake-releasing function, more easy and comfortable to operate; Maintenance-free motor completely solves the problem of DC motor carbon brush.
●New large-screen display instrument provides all kinds of information more clearly and directly for the operator.
●New opened high-range steering design, light to steering and easy to maintain.
●The parking brake adopts electromagnetic brake. It locks the truck automatically after parking, which avoids the sliding danger of the truck caused by forgetting to use the hand brake.
●Side-way battery (optional)
2. Specification
|
Model
|
|
QDD20E(AC)
|
QDD30E(AC)
|
QDD50(AC)
|
QDD60(AC)
|
|
Drive type
|
|
Battery
|
Battery
|
Battery
|
Battery
|
|
Rated traction weight (60 minutes rated)
|
kg
|
2000
|
3000
|
5000
|
6000
|
|
Draw bar center height
|
h1/h2(mm)
|
280/350
|
280/350
|
280/350
|
280/350
|
|
Weight
|
kg
|
740
|
780
|
1240
|
1280
|
|
Axle loading, front
|
kg
|
300
|
310
|
410
|
450
|
|
Axle loading, rear
|
kg
|
440
|
470
|
830
|
830
|
|
Tyre number front/rear
|
X=Driven wheels
|
1/2X
|
1/2X
|
1/2X
|
1/2X
|
|
Tyre size, front
|
solid rubber
|
15*41/2-8
|
15*41/2-8
|
15*41/2-8
|
15*41/2-8
|
|
Tyre size, rear
|
solid rubber
|
15*41/2-8
|
15*41/2-8
|
4.00-8
|
4.00-8
|
|
Rear hanging distance
|
L2(mm)
|
382
|
382
|
500
|
450
|
|
Seat height
|
h3(mm)
|
910
|
910
|
910
|
910
|
|
Overall length
|
L(mm)
|
1720
|
1720
|
1975
|
1940
|
|
Overall width
|
W(mm)
|
968
|
968
|
1100
|
1100
|
|
Overall height
|
H(mm)
|
1270
|
1270
|
1250
|
1250
|
|
Min. ground height
|
X(mm)
|
90
|
90
|
90
|
100
|
|
Min. turning radius
|
Wa(mm)
|
1500
|
1500
|
1650
|
1650
|
|
Travel speed(laden/unladen)
|
km/h
|
7/10
|
6.5
|
8/14
|
7/14
|
|
Wheel base
|
L1(mm)
|
1055
|
1055
|
1250
|
1250
|
|
Max. gradeability(laden/unladen)
|
|
7/12
|
7/12
|
6/15
|
6/15
|
|
Battery voltage, nominal capacity K5
|
V/Ah
|
36/200
|
36/250
|
48/360
|
48/400
|
|
Battery weight
|
kg
|
200
|
250
|
610
|
610
|
|
Traction bolt
|
|
Traction bolt
|
Traction bolt
|
Traction bolt
|
Traction bolt
|
